The Allen-Bradley PLC-5/40V (Part Number 60-0093-01) is a high-performance, VMEbus-compatible programmable logic controller that integrates the proven power of the PLC-5 processor family into a standard VME chassis for high-speed industrial data acquisition and control.
Product Parameters (Datasheet)
- Model Number: PLC-5/40V
- Part Number: 60-0093-01
- Processor Architecture: 1785 Series (PLC-5)
- User Memory: 48K Words (SRAM)
- Total I/O Capacity: 2048 (Any mix) or 2048 In / 2048 Out (Complementary)
- I/O Chassis Per Processor: 61 Max
- Communication Ports: 2x DH+ (Data Highway Plus) / Remote I/O (Adapter or Scanner), 1x RS-232-C/422-A/423-A
- VME Interface: A24/A32:D16/D32 Master/Slave (VME Revision C.1)
- Backplane Current Load: 3.3A @ +5V DC
- Programming Software: RSLogix 5 or 6200 Series
Country of Origin
This controller was designed and manufactured in the United States by Rockwell Automation (Allen-Bradley).
Application Fields
The PLC-5/40V is specifically designed for hybrid systems where VMEbus processing and standard PLC control must coexist:
- Aerospace Testing: High-speed data logging from VME instrumentation combined with machine safety logic.
- Semiconductor Fabrication: Precision timing and motion control within cleanroom VME-based tools.
- Defense & Simulation: Real-time environment simulation and hardware-in-the-loop (HIL) testing.
- Large-Scale Manufacturing: Acting as a supervisor for multiple Remote I/O racks across an assembly plant.
Product Usage Instructions
- VME Slot Selection: Ensure the VME chassis provides adequate power (+5V at 3.3A). The PLC-5/40V is a double-height (6U) module and typically occupies a single slot.
- Memory Backup: Check the internal lithium battery (1770-XY) before installation. This battery maintains the user program and data during power cycles.
- Communication Setup: Use the front-panel 8-pin mini-DIN or 25-pin D-shell ports for programming via DH+ or Serial connections.
- I/O Configuration: Configure the Remote I/O (RIO) scanners via RSLogix 5 to recognize local VME memory maps as I/O image tables for seamless data transfer.
- Thermal Management: Ensure the VME rack has forced-air cooling. The PLC-5/40V generates significant heat during high-speed logic execution.
Product Technical Description
The PLC-5/40V (60-0093-01) bridges the gap between open-architecture VME systems and the industrial reliability of Allen-Bradley’s 1785 platform. Technically, it functions as a “dual-port” device; it executes standard ladder logic while simultaneously allowing other VMEbus masters (like Unix or VxWorks-based CPUs) to read and write directly to its data table memory. This allows for extremely low-latency communication between complex computational tasks on the VMEbus and real-time I/O control on the plant floor.
Q&A (Common Questions)
Q: Can I use standard PLC-5 I/O modules with this controller? A: Yes, via the Remote I/O (RIO) port, this controller can manage any standard 1771-series I/O chassis.
Q: What is the difference between the 5/40V and a standard 5/40? A: The “V” stands for VMEbus. While the processing logic is identical, the 5/40V is a circuit board designed to fit into a VME rack rather than a standard 1771 I/O chassis.
Q: Does it support DH+ communication? A: Yes, it features two configurable channels that support Data Highway Plus (DH+) for peer-to-peer networking or Remote I/O for scanner/adapter functionality.
Q: What happens if the battery dies? A: The red “BATT” LED on the front panel will illuminate. If power is lost while the battery is dead, the user program in the SRAM will be cleared.
Similar Model Recommendations
- Allen-Bradley PLC-5/20V (16K Word version)
- Allen-Bradley PLC-5/80V (100K Word high-capacity version)
- Allen-Bradley 1785-L40B (Standard PLC-5/40 processor)
- Allen-Bradley 1771-ASB (Remote I/O Adapter Module)
- Allen-Bradley 1784-PCMK (Communication card for programming)
