The MOOG FAS H100-V6030-021-02 is a high-performance synchronous brushless servomotor designed for industrial applications requiring extreme precision, high torque-to-inertia ratios, and rapid acceleration capabilities.
Product Parameters (Datasheet)
- Model Number: FAS H100-V6030-021-02
- Motor Type: Permanent Magnet Brushless AC/DC Servomotor
- Rated DC Bus Voltage: 565 Vdc
- Rated Speed: 3000 rpm
- Number of Poles: 6 to 10 poles (depending on specific FAS winding configuration)
- Feedback System: High-resolution resolver or encoder (integrated “021” variant)
- Inertia: Low-inertia design for high-cycle rate applications
- Cooling: Natural convection (IC410)
- Protection Class: IP65 (Standard housing), IP67 (Optional)
- Shaft Type: Plain shaft or keyed shaft (standard industrial dimensions)
Country of Origin
This precision motion component is manufactured by Moog Inc. in Italy (Casella facility), following the high engineering standards of the Moog FAS (Fast Actuating Systems) division.
Application Fields
The FAS H100 series is specifically engineered for high-performance automation:
- Plastic Injection Molding: Precise control of injection speeds and clamping forces.
- Packaging Machinery: High-speed labeling, capping, and pick-and-place robotics.
- Metal Forming: Press feeds and CNC tube bending where rapid start-stop cycles are required.
- Flight Simulation: Providing realistic force feedback and motion platform actuation.
- Textile Equipment: Synchronized high-speed yarn tensioning and weaving.
Product Usage Instructions
- Mounting: Ensure the motor is mounted on a heat-conductive surface to assist with thermal dissipation. Align the shaft precisely with the load to prevent premature bearing wear.
- Wiring: Use high-quality shielded power cables to connect the UVW phases to the servodrive. Ensure the feedback cable (resolver/encoder) is routed away from power lines to minimize signal noise.
- Drive Configuration: This motor is designed for use with 400/480VAC input drives that provide a ~565VDC bus. Input the specific motor constants (Kt, Ke, and phase resistance) into the drive’s firmware.
- Brake Operation: If equipped with an internal holding brake, verify that the 24Vdc supply is active before attempting to rotate the motor shaft.
- Thermal Protection: Connect the internal PTC or KTY temperature sensor to the drive’s monitoring input to prevent winding burnout during overload conditions.
Product Technical Description
The MOOG FAS H100-V6030-021-02 utilizes high-energy rare-earth magnets to achieve a compact footprint with massive power density. Technically, the “H100” series is known for its modular design, allowing for various stack lengths and winding optimizations. The 565Vdc rating makes it perfectly suited for European and North American 3-phase power grids. Its brushless design eliminates mechanical wear associated with commutators, resulting in a maintenance-free lifecycle under normal operating conditions. The integrated feedback unit provides absolute or incremental positioning data with arc-second accuracy.
Q&A (Common Questions)
Q: Can I run this motor at speeds higher than 3000 rpm? A: 3000 rpm is the rated speed at 565Vdc. While the motor may mechanically handle higher speeds, torque will drop off rapidly due to back-EMF, and the drive must support field weakening.
Q: Is the “021-02” suffix specific to the feedback type? A: Yes, these digits usually define the specific resolver or encoder type and the electrical connector orientation (straight or angled).
Q: What is the recommended maintenance schedule? A: Being brushless, the motor requires very little maintenance. Periodically check the shaft seals for leaks and ensure the cooling fins are free of dust and oil buildup.
Q: Can this motor be used in washdown environments? A: With its IP65 rating, it can handle light splashing, but for heavy washdown in food/beverage applications, a stainless steel variant or additional protective covers are recommended.
Similar Model Recommendations
- MOOG FAS H070-V6030 (Smaller frame size variant)
- MOOG FAS H100-V6020 (Lower speed/higher torque winding)
- MOOG D951 series (Integrated drive-motor units)
- MOOG G400 series (High-performance brushless motors)
- MOOG MaxForce (Heavy-duty linear and rotary actuators)
For more information on the MOOG FAS H100-V6030-021-02 and other high-dynamic motion solutions, please contact our technical sales team.
