🔹 Product Introduction
The ABB 5SHX2645L0004 is an Integrated Gate-Commutated Thyristor (IGCT) reverse-conducting power semiconductor module, also identified by ABB order number 3BHL000389P0104. It is designed for high-power electronic conversion applications, including medium-voltage industrial drives, inverter systems, and other power-conversion equipment. The device combines high-voltage switching capability with low conduction losses for demanding industrial power applications.
The module is associated with ABB medium-voltage drive systems and is intended for use within a compatible power stack. Correct installation depends on the designated gate-drive arrangement, cooling system, mechanical clamping force, and electrical configuration. Verify the complete part number and compatibility with the existing converter before replacement. The seller’s listing identifies the item as used, so its actual condition and test status should be confirmed before purchase.
📋 Product Datasheet
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | 5SHX2645L0004 |
| Alternative Part Number | 3BHL000389P0104 |
| Series | ABB IGCT RC Power Semiconductor |
| Product Name | Integrated Gate-Commutated Thyristor Module |
| Place of Manufacture | Not independently confirmed |
| Product Status | Used, according to the referenced listing |
| Dimensions | Exact dimensions not confirmed; check the original part |
| Weight | Approximately 2.6 kg |
| Country of Origin | Seller listing states China; verify product label |
| Power Requirements | High-power switching device; system-dependent |
| Typical Blocking Voltage | Approximately 4500 V, subject to official specification |
| Cooling | Converter-specific thermal management; verify system design |
| Discontinued | Current lifecycle status not confirmed |
⭐ Recommended ABB Models
- 5SHX1445H0002 — IGCT power semiconductor for compatible high-power converter applications.
- 5SHX08F4502 — IGCT-family device; verify electrical ratings and package compatibility.
- 5SHX1960L0004 — High-power semiconductor component for converter systems.
- 5SHY3545L0010 — ABB power semiconductor module for selected drive applications.
- 5SHY4045L0006 — High-power semiconductor device; confirm the exact converter configuration.
- 5SGY3545L0009 — ABB IGCT-family semiconductor component.
- 3BHL000986P3004 — ABB power semiconductor-related part number; verify application compatibility.
- 3BHL000389P0101 — Related ABB order number; confirm revision and interchangeability.
- 5SHX2645L0004 — Original IGCT RC model for replacement identification.
- ACS6000 — ABB medium-voltage drive platform associated with high-power converter technology.
- PM866 — AC 800M controller for industrial process automation.
- PM891 — High-performance AC 800M controller.
- CI854A — PROFIBUS-DP communication interface for compatible AC 800M systems.
- AI810 — Analog input module for compatible ABB control systems.
- AO810 — Analog output module for compatible ABB automation systems.
The semiconductor models are closer to the original component category; the controller and I/O models are broader ABB automation products, not direct replacements. Always confirm voltage and current ratings, gate-drive requirements, cooling, mounting specifications, and converter compatibility before ordering.
