📋 Product Description
The ABB AIM0006, part number 2RCA021397A0001F, is an analog measurement module associated with ABB’s REX615 protection and control platform. Its designation identifies an AIM module with five voltage measurement inputs and four binary inputs, without a BICA chip, according to ABB catalog descriptions. It is intended for supported electrical protection and monitoring configurations where voltage measurements and binary status signals are required.
The module is suitable for applications such as feeder protection, electrical system monitoring, and substation control, subject to the device’s approved configuration. Before purchasing or replacing the unit, verify the complete part number, hardware revision, compatible relay platform, and terminal configuration. Do not assume it is a generic PLC analog output module; confirm the signal types and connection requirements against the applicable ABB documentation.
AIM0006 2RCA021397A0001F
⚙️ Product Parameters
Product Datasheet
🏷️ Brand: ABB
🔢 Model: AIM0006
🆔 Part Number: 2RCA021397A0001F
📦 Series: ABB REX615 Protection and Control Platform
🖥️ Product Name: Analog Measurement Input Module
🌍 Place of Manufacture: Not independently verified
📌 Product Status: Confirm whether New, New Open Box, or Used
📐 Dimensions: Exact dimensions require confirmation from the applicable hardware drawing
⚖️ Weight: Exact weight requires confirmation
🏭 Country of Origin: Verify on the product label
🔌 Power Requirements: Confirm auxiliary supply and power consumption for the specific configuration
🛠️ Discontinued: Confirm current lifecycle status with ABB
📊 Measurement Configuration: AIM 5U + 4BI, without BICA chip
⚡ Measurement Function: Voltage measurement and binary status acquisition
🔧 Application: Electrical protection, feeder monitoring, and substation control
🔧 Recommended ABB Models
The following 15 models are related ABB protection and control components for consideration in compatible REX615 or other ABB protection-system projects. They are not all direct replacements; verify system compatibility before ordering.
- AIM0007 — 2RCA021397A0002: Related analog measurement module.
- AIM0003 — 2RCA025048A0001: Analog measurement module for supported protection configurations.
- AIM0016: Analog input module used in selected REX615 configurations.
- BIO0004 — 2RCA013897A0001: Binary input/output module.
- BIO0005 — 2RCA025501A0001: Binary input/output module for supported configurations.
- BIO0006 — 2RCA025502A0001: Binary input/output module.
- BIO0007 — 2RCA026772A0001: Binary input/output module.
- RTD0001 — 2RCA022949A0001: Resistance temperature detector input module.
- SIM0002 — 2RCA023106A0001: Sensor input module for current and voltage measurements.
- COM0031 — 2RCA023019A0001: Communication module with Ethernet interfaces.
- COM0033 — 2RCA023019A0003: Communication module with Ethernet and fiber-optic connectivity.
- COM0034 — 2RCA023019A0004: Communication module with Ethernet and multimode fiber connectivity.
- PSM0004 — 2RCA025059A0001: Power supply module for supported protection equipment.
- DIS0014 — 2RCA025341A0001: Large-format local human-machine interface display.
- BPL0003: Backplane component for compatible REX615 configurations.
Confirm the exact ordering code and hardware compatibility with ABB documentation before selecting a substitute.
