Description
1. Product Description
⚙️ The ABB DSDI110AV1 (3BSE018295R1) is a 32-channel, 24 VDC digital input board designed for ABB Advant Master and S100 I/O control systems. It receives discrete signals from field devices such as push buttons, limit switches, relay contacts, and equipment status sensors, allowing the controller to monitor industrial processes and machine operating conditions.
🔧 The board features optically isolated digital inputs for interfacing field signals with the control system. It is used in compatible ABB Advant OCS, MasterPiece, and AC 400 system configurations. Before replacement, verify the I/O rack, terminal connection unit, wiring arrangement, and exact hardware revision.
DSDI110AV1 3BSE018295R1
2. Product Parameters and Datasheet
📋 Brand: ABB
Model: DSDI110AV1
Product ID: 3BSE018295R1
Series: Advant Master / S100 I/O
Product Name: 32-Channel Digital Input Board
Product Type: Digital Input Module
Number of Channels: 32
Rated Input Voltage: 24 VDC
Input Signal Type: Digital / Discrete
Isolation: Optically isolated inputs
Compatible Systems: ABB Advant OCS, MasterPiece, and AC 400 configurations
Place of Manufacture: Verify the individual unit; Sweden is listed in product data
Product Status: New Surplus / Used; confirm actual stock condition
Dimensions (H × W × D): 18 × 229.5 × 234 mm
Net Weight: Approximately 0.332 kg
Country of Origin: Verify the product nameplate
Power Requirements: 24 VDC field input signals; system power per rack specifications
Discontinued: Confirm current lifecycle status with ABB
3. Recommended ABB Models
🔩 1. ABB DSDI110 — Digital input board.
2. ABB DSDI120AV1 — Digital input board variant.
3. ABB DSDI130 — Digital input board; verify exact revision.
4. ABB DSDO110 — Digital output board.
5. ABB DSDO115 — Digital output board.
6. ABB DSAI130 — Analog input board.
7. ABB DSAO120 — Analog output board.
8. ABB DSTA131 — I/O connection unit.
9. ABB DSTA180 — I/O connection accessory.
10. ABB DSDP150 — Pulse counter board.
11. ABB DSBC172 — Bus connection unit.
12. ABB DSBC173 — Bus connection unit.
13. ABB PM511V16 — Controller module.
14. ABB PM633 — Controller module.
15. ABB CI626V1 — Advant communication interface; verify system compatibility.
⚠️ These are related ABB Advant and S100 I/O products, not all direct replacements. Confirm channel count, input voltage, rack compatibility, terminal connections, and hardware revision before ordering.
