Description
The ABB PCD530A102, part number 3BHE041343R0102, is identified by ABB as a PC D530 A102 Communication, Control & Measurement (CCM) module. It is associated with ABB industrial automation and power-control applications, where communication, control processing, and measurement functions are combined in one module.
The module is also referenced in connection with ABB AC 800PEC-based systems and excitation/control applications. Its compact construction makes it suitable for integration into industrial control cabinets and specialized power-control equipment.
🔧 Key Features
• ABB industrial control module
• PCD530A102 hardware designation
• 3BHE041343R0102 ABB material number
• Communication, control and measurement functions
• Suitable for industrial automation applications
• Designed for integration into ABB control systems
• Compact modular construction
• Supports real-time process monitoring and control
• Suitable for power and excitation-related applications
📋 Product Datasheet
• Brand: ABB
• Model: PCD530A102
• Part Number: 3BHE041343R0102
• Product Type: Communication, Control & Measurement (CCM) Module
• Associated Platform: ABB AC 800PEC / industrial control systems*
• Main Function: Communication, control and measurement
• Power Supply: 24 VDC system supply*
• Communication: ABB system communication interface*
• I/O Interface: System-dependent*
• Control Function: Real-time industrial process control
• Dimensions: 380 × 142 × 73.5 mm
• Weight: 1.54 kg
• Mounting: Industrial control cabinet / system rack
• Operating Temperature: Approx. -25 to +60 °C*
• Power Consumption: Configuration dependent
• Country of Origin: China, according to one catalog listing*
• Application: Industrial Automation / Power Control
The published ABB catalog-style information confirms the 380 mm depth, 142 mm width, 73.5 mm height, and 1.54 kg net weight.
🏭 Typical Applications
The PCD530A102 can be used in industrial control environments involving:
• Power generation systems
• Generator excitation control
• Industrial automation
• Process monitoring
• Energy management
• Measurement and control systems
• Specialized ABB power-control equipment
⚡ Functional Description
The PCD530A102 is designed around the combined Communication, Control & Measurement (CCM) function. In an installed ABB system, it can serve as an interface for exchanging process information, executing control functions, and handling measurement data.
Its exact I/O and communication configuration depends on the host system and application. For replacement work, matching the complete ABB part number and the original system configuration is more important than relying on generic module specifications.
🔌 Installation & Configuration
Basic installation procedure:
• Verify the complete part number 3BHE041343R0102
• Confirm the host ABB control platform
• Check hardware revision and system configuration
• Install the module in the designated position
• Connect power and system communication interfaces
• Restore the original configuration parameters
• Check module diagnostics after startup
Commissioning should include communication verification, measurement checks, control-function testing, and review of system alarms before returning the equipment to normal operation.
🛠️ Replacement Notes
Before replacing the module, check:
• PCD530A102 identification
• 3BHE041343R0102 material number
• Hardware revision
• Firmware/configuration compatibility
• Connector arrangement
• Existing application parameters
After installation:
• Confirm module power
• Check communication status
• Verify measurement signals
• Check controller diagnostics
• Test connected control functions
• Review alarms and event records
📦 Ordering Information
The correct identification is:
ABB PCD530A102 3BHE041343R0102 | PC D530 A102 | Communication Control & Measurement Module
ABB catalog-style references identify the product as PC D530 A102: Comm. Contr. & Meas. (CCM), with a net size of 380 × 142 × 73.5 mm and a net weight of 1.54 kg.
Some online sources describe this part differently, including as a controller board or excitation module. The ABB catalog description “Communication, Control & Measurement (CCM)” is the safer product classification. Electrical ratings, interfaces, firmware, and environmental specifications marked with an asterisk should be verified against the exact hardware revision before engineering installation.
