1. Product Description
⚙️ The ABB PM865K01 (3BSE031151R1) is a high-integrity processor unit in the AC 800M automation system family. It is designed for industrial process control and safety-related applications, including systems requiring SIL 3 capability when configured with the appropriate safety modules and certified software.
🔧 The PM865K01 kit includes the PM865 CPU, TP830 baseplate, bus terminators, and a memory backup battery. It provides Ethernet and serial communication interfaces for integration with compatible ABB control systems. Verify the hardware revision, safety configuration, and system compatibility before replacement.
PM865K01 3BSE031151R1
2. Product Parameters
📋 Brand: ABB
Model: PM865K01
Product ID: 3BSE031151R1
Series: AC 800M / System 800xA
Product Name: High-Integrity Processor Unit
Processor: MPC862P
CPU Clock Frequency: 96 MHz
Memory: 32 MB
Safety Integrity: SIL 3 capability with the required configuration
Communication Interfaces: 2 Ethernet ports and 2 serial ports
Power Requirements: 24 V DC nominal
Dimensions: Approximately 119 × 186 × 135 mm (W × H × D)
Weight: Approximately 1.2 kg
Place of Manufacture: To be confirmed
Country of Origin: Verify from product nameplate
Product Status: Classic lifecycle status
Discontinued: Confirm current ordering availability with ABB
3. Recommended ABB Models
🔩 1. ABB PM865K02 — Redundant processor unit kit.
2. ABB PM867K01 — High-integrity processor unit for newer installations.
3. ABB PM866AK01 — AC 800M controller.
4. ABB PM861AK01 — AC 800M controller.
5. ABB PM864AK01 — AC 800M controller.
6. ABB PM856K01 — AC 800M controller.
7. ABB PM851A — AC 800M controller.
8. ABB SM811K01 — Safety CPU module kit.
9. ABB SM812K01 — Safety module kit.
10. ABB TP830 — Processor baseplate.
11. ABB CI854A — PROFIBUS communication interface.
12. ABB CI867K01 — Modbus TCP communication interface.
13. ABB AI815 — Analog input module.
14. ABB AO810 — Analog output module.
15. ABB SS823 — Voting device for high-integrity systems.
⚠️ These are related ABB automation products, not all direct replacements. For safety-related systems, verify the approved configuration and safety manual before substitution.
