Description
The ABB PP845 (Part Number: 3BSE042235R1) is a high-performance operator interface from the Panel 800 series. It features a 7.0-inch widescreen TFT-LCD color display with touchscreen functionality. Designed for the 800xA automation platform and other third-party controllers, it provides a robust, user-friendly interface for process monitoring and machine control.
Product Parameters (Datasheet)
- Model Number: PP845
- Part Number: 3BSE042235R1
- Display Type: 7.0″ TFT-LCD (16:9 Widescreen)
- Resolution: 800 x 480 pixels
- Backlight: LED (Dimmable)
- Touchscreen: Resistive
- Processor: ARM9 (400 MHz)
- Memory: 128 MB Flash, 128 MB RAM
- Interfaces: * 1 x Ethernet (10/100 Base-T)
- 2 x Serial Ports (RS-232, RS-422/485)
- 1 x USB 2.0 (Host)
- Operating Voltage: 24 V DC (18–32 V DC)
- Protection Rating: IP65 (Front), IP20 (Rear)
ABB PP845 3BSE042235R1
ABB PP845 3BSE042235R1
ABB PP845 3BSE042235R1
Country of Origin
This HMI panel is engineered and manufactured by ABB in Sweden, ensuring compatibility with global industrial standards and the ABB 800xA ecosystem.
Application Fields
The PP845 is versatile and used across various industrial sectors:
- Process Automation: Controlling pumps, valves, and heaters in chemical and water treatment plants.
- Manufacturing: Serving as a machine-side interface for CNC machines or assembly lines.
- Oil & Gas: Monitoring local tank levels and pressure sensors in hazardous or remote locations.
- Food & Beverage: Managing recipe selection and clean-in-place (CIP) sequences.
- Marine: Displaying engine diagnostics and ballast control systems on ships.
Product Usage Instructions
- Panel Cutout: Prepare the cabinet door using the precise dimensions provided in the ABB installation manual. Ensure the gasket is seated correctly to maintain the IP65 rating.
- Power Connection: Connect a stabilized 24 V DC power source to the terminal block. Ensure the polarity is correct to prevent internal fuse damage.
- Communication Setup: Use the Ethernet port for connection to ABB AC 800M controllers or the serial ports for Modbus RTU communication with third-party PLCs.
- Configuration: Download your HMI project using the Panel Builder 800 software tool. Projects can be transferred via Ethernet or a USB flash drive.
- Screen Maintenance: Clean the resistive touch surface with a soft, damp cloth. Avoid using sharp objects or harsh chemicals that could degrade the protective film.
Product Technical Description
The PP845 is more than just a display; it is a dedicated industrial computer. Technically, it runs a real-time operating system optimized for graphics rendering and data handling. It supports advanced features such as Alarm Management, Trend Logging, and Recipe Management. The inclusion of dual serial ports and an Ethernet port allows the PP845 to act as a data concentrator, simultaneously communicating with multiple different brands of PLCs. Its aluminum-reinforced housing provides high resistance to vibration and electromagnetic interference, making it suitable for mounting directly on heavy machinery.
Q&A (Common Questions)
- Q: Can the PP845 communicate with Siemens or Rockwell PLCs?
- A: Yes. Through the Panel Builder 800 software, you can select drivers for various third-party protocols, including Siemens S7, Rockwell EtherNet/IP, and Modbus.
- Q: My screen is unresponsive to touch; what should I check?
- A: First, try cleaning the edge of the bezel to ensure no debris is pressing against the resistive surface. If the issue persists, use the software’s calibration utility to re-align the touch coordinates.
- Q: Is there a replacement for the older PP836 or PP846?
- A: The PP845 is part of the updated Panel 800 range. While it may serve a similar purpose, check the physical cutout dimensions and communication port requirements, as they may differ from older models.
- Q: Does this panel support multi-touch (pinching/zooming)?
- A: No. The PP845 uses a resistive touchscreen designed for single-point pressure, which is ideal for operators wearing gloves.
Similar Model Recommendations
- ABB PP815: Smaller 4.3″ version for compact machines.
- ABB PP875: Larger 10.4″ version for complex process overviews.
- ABB PP885: 15″ high-resolution panel for centralized control.
- ABB AC 800M: The primary controller series used in conjunction with this panel.
- ABB PM864K01: Processor unit often integrated with Panel 800 systems.
For technical manuals or to request a quote for the ABB PP845, please contact our HMI and visualization technical team.
