Description
The ABB SD812F (part number 3BDH000014R1) is a high-efficiency switch-mode power supply unit designed for the Freelance distributed control system (DCS). It provides a stabilized 24V DC output, ensuring the reliable operation of CPU modules, I/O stations, and field sensors in demanding industrial environments.
Technical Datasheet
| Feature | Specification |
| Model Number | SD812F |
| Part Number | 3BDH000014R1 |
| Manufacturer | ABB |
| Input Voltage Range | 100-240V AC (Wide Range) / 110-250V DC |
| Output Voltage | 24V DC (Adjustable) |
| Output Current | 10A |
| Power Rating | 240W |
| Efficiency | > 90% |
| Redundancy | Supported via external diode modules |
ABB SD812F 3BDH000014R1
Key Features
- Universal Input: Supports a wide range of AC and DC input voltages, making it compatible with various global power standards.
- Overload Protection: Integrated short-circuit and over-voltage protection to prevent damage to sensitive downstream electronics.
- Status Monitoring: Features dry contacts (Power Good signal) and front-panel LEDs for immediate diagnostic feedback on output health.
- DIN Rail Mounting: Designed for easy installation in standard control cabinets with high vibration resistance.
- Conformal Coating: Often used in harsh environments where moisture or corrosive gases may be present.
ABB SD812F 3BDH000014R1
Product Overview
The SD812F is a critical component for maintaining system uptime. It is specifically engineered to meet the high-availability requirements of ABB’s Freelance architecture, often powering the AC 800F or AC 700F controllers. Its high efficiency minimizes heat dissipation within the cabinet, extending the lifespan of adjacent components.
