Description
The ABB UAD155A0111 (3BHE029110R0111) is an AC 800PEC Combi IO Box controller board designed for ABB high-performance industrial automation and power electronics control applications. It provides integrated control processing and I/O interface functions within ABB AC 800PEC systems.
The module is used for fast signal processing, control communication, and interface management in demanding automation environments such as power converters, excitation systems, and industrial drive applications.
🔧 Control Function
The UAD155A0111 works as a controller board inside the ABB AC 800PEC platform. It combines processing capability with I/O interface functions, allowing connection between field signals, control logic, and higher-level automation systems.
The board supports high-speed control applications where accurate signal acquisition, fast response, and stable communication are required.
🏭 Typical Applications
• ABB AC 800PEC control systems
• Power converter control
• Excitation control systems
• Industrial drive applications
• Energy automation systems
• Power generation equipment
• High-performance process control
• Electrical system monitoring
📋 Product Datasheet
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | UAD155A0111 |
| Part Number | 3BHE029110R0111 |
| Product Type | AC 800PEC Combi IO Box Controller Board |
| Controller Platform | ABB AC 800PEC |
| Main Function | Control Processing & I/O Interface |
| Board Type | Controller Board |
| I/O Function | Combined Analog / Digital I/O Interface* |
| Communication | ABB Control System Communication |
| Processing Function | High-Speed Control Processing |
| Power Supply | 24 VDC |
| Power Consumption | Approx. ≤8 W* |
| Installation | AC 800PEC System Assembly |
| Mounting Type | Control Cabinet Installation |
| Operating Temperature | -25°C to +70°C* |
| Storage Temperature | -40°C to +85°C* |
| Dimensions | Configuration-dependent |
| Weight | Approx. 2.947 kg |
| Country of Origin | China / Thailand* |
| Application Field | Industrial Automation & Power Control |
*Specifications may vary depending on hardware revision and system configuration.
⚡ Key Features
• ABB AC 800PEC controller board design
• Integrated control and I/O interface functions
• Suitable for high-speed industrial control tasks
• Designed for power electronics applications
• Supports reliable signal processing
• Compatible with ABB automation architectures
• Used in demanding industrial environments
🔌 Communication & Integration
The ABB UAD155A0111 integrates into AC 800PEC control systems and exchanges data with connected I/O devices, control modules, and automation networks.
Typical system configuration includes:
• Install the controller board in the AC 800PEC hardware platform
• Configure I/O channels and control parameters
• Verify communication settings
• Load application software
• Check diagnostic information
• Perform system testing
🛠️ Installation Notes
Before installation, verify the complete identification UAD155A0111 / 3BHE029110R0111, hardware revision, AC 800PEC compatibility, and existing control configuration.
Disconnect system power before replacing the module. Check connectors, grounding, supply voltage, and cabinet wiring before startup.
After installation, verify controller status, communication links, I/O operation, and system diagnostics.
⚙️ Commissioning Checklist
• Confirm ABB part number
• Verify AC 800PEC compatibility
• Check 24 VDC power supply
• Inspect connectors and wiring
• Configure I/O parameters
• Verify communication status
• Check diagnostic messages
• Test control functions
• Record operating parameters
⚠️ Compatibility Notice
The ABB UAD155A0111 3BHE029110R0111 is a dedicated AC 800PEC controller board. It is not a standard PLC CPU module and requires the correct ABB hardware platform, engineering configuration, and application software.
For replacement projects, confirm firmware version, hardware revision, I/O configuration, and existing AC 800PEC system design before installation.
📦 Product Identification
Brand: ABB
Model: UAD155A0111
Part Number: 3BHE029110R0111
Product Type: AC 800PEC Combi IO Box Controller Board
Function: Control Processing & I/O Interface
Application: Power Electronics / Industrial Automation
System: ABB AC 800PEC
