Advantest BGR-022365 A000824B-DED | Semiconductor Test Board

Description

• Model: Advantest BGR-022365 (A000824B-DED)
• Brand: Advantest (Japan)
• Series: T-Series / V93000 Compatible Interface Components
• Core Function: High-speed signal interface board for semiconductor ATE systems
• Product Type: Performance Board / Interface Card
• Key Specs: Multi-layer high-impedance PCB | Gold-plated contact points | Low-latency signal paths

• Layer Count: High-density multi-layer BOARD construction
• Connector Type: High-insertion cycle precision headers
• Operating Temp: 10 °C to 45 °C (Controlled cleanroom environment)
• Signal Integrity: Optimized for GHz-range frequency response
• Impedance Control: 50 Ω (typical, application dependent)
• Compliance: SEMI S2/S8 standards
• Weight: Approx. 1.2 kg
• Mounting: Rack-slide or direct-mate interface

ADVANTEST BGR-022365 A000824B-DED

Application Scenarios & Pain Points

In the semiconductor testing world, every second of “prober down” time equates to thousands of dollars in lost throughput. When an interface board like the BGR-022365 develops a hairline fracture or a contact failure due to mechanical fatigue, the entire test cell grinds to a halt. Finding these specific Advantest legacy boards through official channels can often take months—a timeline that is simply non-existent for high-volume fabrication plants.

Typical Application Scenarios:

1. Semiconductor Wafer Testing Used as the bridge between the tester electronics and the probe card, ensuring signal purity for delicate silicon wafers.
2. Final Test (FT) Operations Integrated into the test head assembly to facilitate high-speed logic or memory chip verification.
3. Legacy System Extension Supporting older T-series or V-series testers that are no longer the primary focus of OEM support but remain workhorses in the lab.

The “2 AM Emergency” Case:

A major OSAT (Outsourced Semiconductor Assembly and Test) provider in Southeast Asia experienced intermittent “Signal Noise” errors on their primary memory tester. After four hours of swapping cables and recalibrating software, the onsite engineer traced the fault to a degraded pin on the BGR-022365 interface board.

The OEM quoted a 10-week lead time. By sourcing our verified surplus A000824B-DED, they had the tester back in production within 72 hours, saving an estimated $120,000 in missed delivery penalties.

ADVANTEST BGR-022365 A000824B-DED

Quality Control & SOP Transparency

We don’t just “box and ship.” Semiconductor test equipment requires extreme precision. Here is how we verify this BGR-022365 board before it reaches your cleanroom:

1. Visual Micro-Inspection: We use a high-resolution digital microscope to check for micro-cracks in the PCB traces and ensure the gold-plating on the interface pins is free from pitting or oxidation.
2. Continuity & Impedance Check: Using a Fluke 115 and, where applicable, a Time-Domain Reflectometer (TDR), we verify that signal paths meet the original 50 Ω specification.
3. Mounting Integrity: We test the mechanical seating of the A000824B-DED to ensure it locks into the tester frame without resistance or misalignment.
4. ESD-Safe Handling: All tests are performed in an ESD-protected area (EPA) with technicians wearing grounded wrist straps. The board is then sealed in a metallic moisture-barrier bag (MBB) with desiccant.

Note: We can provide high-res photos of the specific serial number and pins before you finalize the purchase.
