Description
The Bently Nevada 125768-01 is a critical component of the 3300 XL 8 mm Proximity Transducer System. It serves as an interface between the proximity probe and the monitoring system, converting the high-frequency radio signal from the probe into a proportional voltage output. This sensor is essential for non-contact measurement of vibration, displacement, and axial position in rotating machinery, ensuring operational safety and predictive maintenance of critical industrial assets.
Key Technical Specifications
- System Compatibility: Designed for use with 3300 XL 8 mm proximity probes and extension cables
- Operating Temperature: -51°C to +177°C, allowing for deployment in harsh industrial environments
- Output Impedance: 50 Ω nominal output impedance for signal integrity
- Linear Range: 2 mm (80 mils) of linear measurement range
- Power Supply: -17.5 VDC to -26 VDC operating voltage range
- Sensitivity: 7.87 V/mm (200 mV/mil) for precise signal conversion
- Mounting Options: DIN-rail or panel-mount configuration flexibility
- Electrical Safety: Designed to meet rigorous hazardous area requirements (intrinsically safe)
- Frequency Response: 0 to 10 kHz to capture both low and high-frequency vibrations
- Cable Termination: Standardized connector system to ensure consistent system calibration
Related Bently Nevada 3300 XL Series Model Recommendations
For a complete machinery protection and condition monitoring setup, the following components are commonly utilized alongside the 125768-01:
- 330101: 3300 XL 8 mm standard proximity probe.
- 330130: 3300 XL 8 mm extension cable.
- 3300 XL 11 mm: Proximity transducer system for larger radial clearance measurements.
- 330106: 3300 XL 8 mm probe with armored cable.
- 330900: 3300 XL 5 mm proximity probe for restricted space applications.
- 330105: 3300 XL 8 mm probe with fluidloc cable.
- 125840-01: 3300 XL 8 mm Proximitor Sensor (alternative calibration).
- 330190: 3300 XL 8 mm proximity probe mount.
- 330180: 3300 XL 8 mm probe housing.
- 3300/16: Dual vibration monitor module for 3300 series rack integration.
