Description
The Bently Nevada 135473-01 is a high-quality extension cable designed for use within the 3300 XL 8 mm Proximity Transducer System. This cable serves as the critical link between the proximity probe and the Proximitor sensor, ensuring the transmission of high-frequency electrical signals without interference. It is engineered to maintain signal integrity in harsh industrial environments, featuring rugged shielding and specific electrical characteristics that match the system’s calibration requirements.
Key Technical Specifications
- System Compatibility: Specifically designed for the 3300 XL 8 mm Proximity Transducer System
- Cable Length: 4.0 meters (total system length including probe must be 5 or 9 meters for standard calibration)
- Conductor Material: High-grade stranded copper for flexibility and durability
- Shielding: Multi-layered RFI/EMI shielding to prevent signal noise in industrial settings
- Connector Type: ClickLoc™ connectors, which lock securely to prevent accidental disconnection
- Jacket Material: Fluoroelastomer (or equivalent) for chemical and oil resistance
- Temperature Rating: Designed to withstand ambient temperatures up to +177°C
- Capacitance: Precisely matched to the system’s impedance to ensure linear signal output
- Ingress Protection: Designed for oil-tight, dust-proof installations when used with appropriate conduit
- Durability: Resistant to harsh chemicals, vibration, and mechanical stress
Related Bently Nevada 3300 XL Series Model Recommendations
For an optimized and compliant 3300 XL Proximity Transducer System installation, the following components are frequently paired with the 135473-01:
- 330101: 3300 XL 8 mm standard proximity probe (various lengths).
- 330105: 3300 XL 8 mm probe with Fluidloc® cable.
- 125768-01: 3300 XL 8 mm Proximitor Sensor (standard calibration).
- 330106: 3300 XL 8 mm probe with stainless steel armor.
- 330130: 3300 XL extension cable (standard 3.5-meter variant).
- 330180: 3300 XL 8 mm probe housing and mounting accessories.
- 330190: 3300 XL 8 mm probe reverse-mount configuration.
- 330900: 3300 XL 5 mm proximity probe for space-constrained environments.
- 330103: 3300 XL 8 mm probe with reverse mount.
- 125840-01: 3300 XL 8 mm Proximitor Sensor (alternate configuration).
