⚙️ Product: 136719-01
🏷️ Brand: BENTLY NEVADA
🖥️ Series: 3500
🔧 Product Type: Earthing I/O Module
The BENTLY NEVADA 136719-01 is the Earthing I/O Module used with the 3500 Machinery Protection System. Bently Nevada documentation identifies 136719-01 as the module for the 3500/04 earthing function. It is associated with systems using internal barriers and provides the required grounding interface within the rack architecture.
🛡️ The module is a system-level interface component rather than a vibration measurement monitor. It is used in 3500 racks where internal barrier arrangements require the dedicated earthing module. Bently Nevada’s 3500/04 documentation lists 136719-01 as the Earthing I/O Module spare.
🔌 Before installation, verify the rack configuration, internal barrier option, module position, grounding arrangement, and compatibility with the installed 3500 I/O modules.
Product Datasheet
🔹 Model: 3500/04
🔹 Part Number: 136719-01
🔹 Brand: BENTLY NEVADA
🔹 Product Type: Earthing I/O Module
🔹 System: 3500 Machinery Protection System
🔹 Function: Earthing / Grounding Interface
🔹 Application: Internal Barrier Protection and Rack Grounding
🔹 Electrical Requirement: Passive Earthing Interface
🔹 Communication: No Independent Communication Interface
🔹 Mounting: Bently Nevada 3500 Rack
🔹 Dimensions: Approx. 160 × 160 × 120 mm*
🔹 Weight: Approx. 0.8 kg*
🔹 Country of Origin: USA*
*Dimensions and weight can vary with packaging and hardware configuration. Verify the actual module markings and applicable Bently Nevada documentation before installation.
Typical Applications
⚙️ 3500 Machinery Protection Systems
🛡️ Internal barrier installations
⚡ Turbine and generator protection
🏭 Rotating machinery monitoring
🛢️ Oil and gas machinery protection
🔄 3500 system maintenance and replacement
Installation & Use
🛠️ Confirm that the 3500 rack uses the appropriate internal-barrier configuration before installing the 136719-01. Check the designated I/O position and grounding arrangement.
🔌 With the rack safely de-energized, install the module in the specified position and verify the mechanical and electrical connections. Follow the approved grounding and hazardous-area installation practices for the application.
⚠️ After installation, inspect the grounding path and associated internal-barrier connections. Complete the required rack diagnostics and system verification before returning the machinery protection system to service.
