Description
The Bently Nevada 136719-01 is a high-reliability Triple Modular Redundant (TMR) Relay Module designed for the 3500 Machinery Protection System. This module is specifically engineered to provide critical alarm and trip functions for rotating machinery. By utilizing a TMR architecture, it ensures that the system continues to operate reliably even in the event of a single component failure, providing the high level of safety and availability required in mission-critical industrial environments.
Technical Specifications ⚙️
| Feature | Specification |
|---|---|
| Product Type | TMR Relay Module |
| Series | Bently Nevada 3500 System |
| Part Number | 136719-01 |
| Redundancy | Triple Modular Redundant (TMR) architecture |
| Operating Voltage | 24 VDC (Backplane powered) |
| Output Channels | Configurable relay outputs |
| Status Indication | Front panel LEDs for OK, TX/RX, and Relay status |
| Mounting | Standard 3500 Rack slot |
| Isolation | Galvanically isolated relay contacts |
| System Compatibility | Designed for integration with 3500/20 and 3500/22M |
