Description
- Model Number: CE3008
- Part Number: KJ2005X1-MQ1 / 12P6381X022
- Series: DeltaV S-series
- Processor Type: MQ Controller
- Input Voltage: 24V DC (via System Power Supply)
- Communication Ports: * 2 x Ethernet (Redundant Control Network)
- 1 x Local Bus (for I/O communication)
- Operating Temperature: -40°C to +70°C (-40°F to 158°F)
- Redundancy: Supported (Requires redundant controller carrier)
Product Description The Emerson CE3008 (KJ2005X1-MQ1) is a high-performance MQ Controller designed specifically for the DeltaV S-series Distributed Control System (DCS). This controller provides the local intelligence and processing power required to execute complex control strategies and manage I/O communication in real-time. The “S-series” hardware features an “I/O on Demand” architecture, and the MQ controller is capable of handling traditional wired I/O, wireless I/O, and CHARMs (Characterization Modules) simultaneously. Its robust design allows for installation in harsh industrial environments, and its “plug-and-play” capability enables the controller to be automatically recognized and configured by the DeltaV network.
Application Areas This controller is a core component for process automation in industries such as Oil & Gas, Chemicals, Life Sciences, and Power Generation. It is ideal for applications requiring high availability, flexible I/O scaling, and integrated safety and control logic execution.
Product Specifications
- Weight: 0.55 kg
- Dimensions: 15.9 cm x 10.7 cm x 4.5 cm
- Country of Origin: USA
- Memory: High-capacity non-volatile flash for strategy storage
- Vibration/Shock: Meets ISA-S71.04-1985 Class G3 harsh environmental standards
EMERSON CE3008
EMERSON CE3008
EMERSON CE3008
Operational Precautions
- Carrier Compatibility: The CE3008 must be seated on a compatible S-series controller carrier. Ensure the carrier is properly grounded to the cabinet rail to prevent communication noise.
- Redundancy Setup: For mission-critical loops, utilize a redundant pair. The DeltaV system manages the switchover automatically, but both controllers must have identical hardware revisions and firmware versions.
- Firmware Version: Before commissioning, verify that the controller firmware is compatible with your DeltaV software version (e.g., v12, v14). Incompatible firmware will prevent the controller from going “Online.”
- Hot-Swapping: This module is hot-swappable. However, if removing a non-redundant controller, ensure the process is in a safe manual state, as all associated I/O control will cease immediately.
Recommended Similar Product Models
| Model Number | Product Category | Feature Set |
|---|---|---|
| CE3007 | Controller | MD Plus Controller (S-series) |
| KJ2005X1-BA1 | Controller | M5 Controller |
| KJ3222X1-BA1 | CHARM I/O | Characterization Module Base |
| KJ3001X1-BA1 | Power Supply | System Power Supply (S-series) |
| KJ4001X1-BA1 | Carrier | S-series Controller Carrier |
