Description
The FOXBORO FBM219 (P0916RH) is a high-density Discrete Input Interface Module designed for use within the I/A Series and EcoStruxure Foxboro DCS. This module provides 32 discrete input channels, allowing for the seamless integration of field switches, contacts, and other digital signals into the control system. Engineered for high reliability in demanding industrial environments, the FBM219 ensures precise signal monitoring and fast response times for critical process control and interlocking functions.
Product Specifications
- Model Identification: Foxboro FBM219 (Part Number: P0916RH)
- Input Channels: 32 Isolated Discrete Input Channels
- Input Voltage: 24V DC (nominal)
- Communication Interface: Fieldbus Module (FBM) protocol
- Power Consumption: Low-power consumption design for reduced heat dissipation
- Isolation: Galvanic isolation between field circuits and system logic
- Dimensions: 102 mm x 45 mm x 114 mm
- Weight: 0.28 kg
- Country of Origin: USA
FOXBORO FBM219 P0916RH
FOXBORO FBM219 P0916RH
FOXBORO FBM219 P0916RH
FOXBORO FBM219 P0916RH
Application Fields
The FOXBORO FBM219 is a versatile component found in various heavy industries requiring large-scale digital monitoring:
- Refining & Petrochemicals: Monitoring valve limit switches and pump status.
- Power Generation: Tracking breaker positions and auxiliary equipment states in steam and gas turbine plants.
- Pulp & Paper: Managing sequence control for large processing conveyors and digesters.
- Water & Wastewater: Supervising level switches and motor control centers (MCC).
- Mining & Metals: Integrating safety interlocks and conveyor belt misalignment switches.
Product Operation Instructions
- Installation: Insert the FBM219 into a compatible Foxboro modular baseplate. Ensure the module is firmly seated and the locking mechanism is engaged.
- Field Wiring: Connect field devices to the appropriate Terminal Assembly (TA). The FBM219 typically uses a dedicated compression-type or screw-terminal TA for wiring organization.
- System Integration: Use the Foxboro Control Processor configuration software (such as I/A Series Letterpicker or EcoStruxure Foxboro DCS Control Software) to assign the module to the correct I/O address.
- Signal Validation: Verify the status of field inputs via the system workstation. The module supports per-channel LED indicators on the baseplate or through software diagnostics to confirm signal presence.
- Environmental Care: Ensure the cabinet housing the module is kept within the specified temperature and humidity ranges to prevent premature aging of the electronic components.
Q&A: Common Questions
Q: Does the FBM219 support sequence of events (SOE) recording? A: Yes, when configured with the appropriate system software, the FBM219 can provide high-resolution time-stamping for discrete events, making it ideal for root cause analysis.
Q: Can I replace an FBM219 module while the system is powered? A: Yes, Foxboro FBMs are designed for “Hot Swapping,” allowing you to replace a faulty module without shutting down the entire baseplate or the Control Processor.
Q: What is the difference between P0916RH and other FBM219 versions? A: The P0916RH part number specifically identifies the hardware revision and manufacturing series. Always ensure compatibility with your existing baseplate and software version before installation.
