Description
The GE V7768-322001 (Part Number 350-9301007768-322001 A2) is a high-performance 6U VMEbus Single Board Computer (SBC) designed for rugged industrial, aerospace, and defense applications. Leveraging the Intel Pentium M processor architecture, this board provides a powerful balance of computational efficiency and low power consumption, making it ideal for legacy system upgrades and high-reliability embedded processing.
Product Introduction
The V7768-322001 is engineered to provide a seamless migration path for VME-based systems requiring increased bandwidth and processing speed. It features an integrated chipset that supports high-speed memory and versatile I/O options. The “A2” designation indicates a specific hardware revision or build standard, ensuring compatibility with demanding environmental specifications and long-term lifecycle support.
GE V7768-322001 350-9301007768-322001 A2
Product Parameters (Datasheet)
| Parameter | Specification |
| Processor | Intel Pentium M (typically 1.6 GHz to 1.8 GHz) |
| L2 Cache | 2 MB Integrated |
| System Memory | Up to 2 GB DDR SDRAM with ECC |
| VME Interface | Tundra Tsi148 (VME64 / 2eSST support) |
| Ethernet | Dual 10/100/1000Base-T Gigabit Ethernet |
| USB Ports | 2x USB 2.0 ports |
| Serial I/O | 2x RS-232/422/485 programmable ports |
| Storage | CompactFlash socket and SATA support |
| Expansion | Dual PMC slots (PCI Mezzanine Card) |
| Operating Temp | 0°C to +55°C (Standard); -40°C to +85°C (Ruggedized) |
Country of Origin
- Origin: United States (USA) / United Kingdom (UK)
GE V7768-322001 350-9301007768-322001 A2
Product Technical Features
- VME64 Extension: Utilizes the Tsi148 bridge to achieve data transfer rates of up to 320 MB/s via 2eSST protocols.
- PMC Flexibility: Dual PMC sites allow for the addition of specialized I/O such as MIL-STD-1553, ARINC 429, or additional graphics controllers.
- Low Power Design: Optimized for conduction-cooled or air-cooled environments where thermal management is a priority.
- Operating System Support: Fully compatible with VxWorks, LynxOS, Windows Embedded, and Linux.
Product Q&A
- Q: Can the V7768-322001 replace older V7750 or V7769 boards?
- A: Yes, the GE V7768-322001 is designed to be backward compatible with many legacy GE/Fanuc VME pinouts, though software drivers may need updating.
- Q: Does this board support ECC memory?
- A: Yes, the system utilizes Error Correcting Code (ECC) SDRAM to ensure data integrity in high-radiation or high-interference environments.
- Q: What is the significance of the “A2” suffix?
- A: The A2 suffix refers to the hardware revision level, which typically includes minor component updates or optimizations for improved reliability over the original A1 release.
GE V7768-322001 350-9301007768-322001 A2
Recommended Similar Models
- GE V7768-110001: Standard 1.6GHz version with varying memory configurations.
- GE V7865: A higher-performance successor featuring Intel Core Duo processors.
- Abaco/GE V7750: Legacy Pentium III VME processor board.
- GE V7807: Rugged Intel Core i7 based 6U VME SBC.
- GE V7769: Similar architecture with advanced graphics support (AGP).
