⚙️ The GE Fanuc VMIVME-2128 is a 128-bit high-voltage digital output board designed for VMEbus-based industrial control and embedded computing systems. It provides high-density discrete output channels for controlling compatible external loads, including relays, solenoids, and indicators.
🔧 The board features open-collector output drivers, built-in test (BIT) logic, output register readback, automatic surge-current shutdown, thermal protection, and output clamp diodes for inductive loads. It uses a 6U VME form factor and is suitable for maintaining legacy industrial automation and test systems. The original VME-2128 reached end of life on April 19, 2018; the VME-2128A is identified by Abaco Systems as a form-fit-function replacement, subject to configuration verification.
VMIVME-2128
2. Product Parameters
📋 Brand: GE Fanuc / VMIC
Model: VMIVME-2128
Series: VMIC VMEbus I/O
Product Name: 128-Channel High-Voltage Digital Output Board
Number of Outputs: 128 digital output channels
Output Type: Open-collector, high-current sink
Output Voltage Range: 5–48 VDC, depending on configuration
Maximum Sink Current: 600 mA per channel
Maximum Breakdown Voltage: 55 V
Bus Interface: VMEbus, A24/A16 addressing
Data Transfer: 8-bit, 16-bit, and 32-bit
Form Factor: 6U Eurocard
Connectors: Two 96-pin female output connectors
Protection: Surge-current shutdown, thermal shutdown, inductive flyback clamp diodes
Diagnostics: Built-in test logic and output register readback
Power Requirements: VME backplane supply; confirm complete system requirements in the hardware manual
Place of Manufacture: To be confirmed
Product Status: Legacy product; verify actual stock condition
Dimensions: 6U VME form factor; verify exact board dimensions in the manual
Weight: Not verified
Country of Origin: Check product nameplate
Discontinued: Yes; original VME-2128 reached end of life in 2018
3. Recommended GE Fanuc / VMIC Models
🔩 1. GE / Abaco VME-2128A — 128-channel high-voltage digital output board; designated form-fit-function replacement.
2. GE VMIVME-2120 — Digital output board family; verify specifications.
3. GE VMIVME-2122 — Digital output board family; verify configuration.
4. GE VMIVME-2123 — Digital output board family; verify compatibility.
5. GE VMIVME-2130 — Digital I/O family; verify exact function.
6. GE VMIVME-2140 — Digital I/O board family; verify specifications.
7. GE VMIVME-3122 — Analog input board.
8. GE VMIVME-3123 — Analog input board.
9. GE VMIVME-3124 — Analog input board.
10. GE VMIVME-4100 — Analog output board family; verify configuration.
11. GE VMIVME-4140 — Analog output board family; verify specifications.
12. GE VMIVME-5565 — Reflective memory interface family.
13. GE VMIVME-7700 — Embedded VME controller family.
14. GE VMIVME-7807 — Embedded VME controller family.
15. GE VMIACC-BT10 — DIN-rail transition module for compatible I/O connectors.
⚠️ These are related VMEbus product-family suggestions, not guaranteed direct replacements. For the VME-2128A, verify output configuration, pull-up resistor options, connector wiring, load current, and software compatibility before substitution.
