GE IC698RMX016-ED | PACSYSTEMS RX7i 16MB REDUNDANCY MODULE
GE IC698RMX016-ED | PACSYSTEMS RX7i 16MB REDUNDANCY MODULE - Image 2
GE IC698RMX016-ED | PACSYSTEMS RX7i 16MB REDUNDANCY MODULE - Image 3

GE IC698RMX016-ED | PACSYSTEMS RX7i 16MB REDUNDANCY MODULE

Original price was: $10,000.00.Current price is: $1,050.00.

Product NO： IC698RMX016-ED

Brand：GE

Delivery time:  In stock

Product status:   Brandnew

Product situation: one year warranty, Origin of Manufacture

Add to quote
Category: Tags:
Felix Sales Manager
[email protected] +86 138 2210 1417 8613822101417
WhatsApp
QR
Chat Now
There are still many products that have not been released yet. If you have any products that you cannot find, you can ask me for a quote! Reminder: The product images published on this website are not actual real products and are for reference only!

Description

Hardware Specifications

  • Manufacturer: General Electric (GE / Emerson PACSystems)
  • Part Number / Revision: IC698RMX016-ED
  • Product Series: PACSystems RX7i Platform
  • Module Type: Redundancy Memory Xchange (RMX) / Reflective Memory Module
  • Memory Capacity: 16 MB SDRAM user memory
  • Data Transfer Rate: High-speed fiber-optic network interface supporting up to 2.12 Gbaud
  • Network Topology: Ring topology utilizing fiber-optic cabling (supports up to 256 nodes)
  • Optical Connectors: Dual LC-type fiber-optic ports
  • Power Consumption: +5 V DC drawn directly from the VME backplane (approx. 1.8 A)
  • Form Factor: Single-slot plug-in VME64 module for RX7i main racks



Installation & Configuration Guidelines

  • Slot Placement: Recommended for installation in Slots 3 and 4 of the main RX7i rack to ensure proper VME interrupt request priority for redundant CPU communication.
  • Backplane Seating: Power down the chassis completely before sliding the module smoothly along the guide rails and securing the top and bottom faceplate screws.
  • Fiber Optic Cabling: Connect fiber patch cables in a closed-loop ring configuration (Transmitter TX of one node connected to the Receiver RX of the next node).
  • Configuration Dependency: The module boots up in an unconfigured state with its optical transmitters disabled by default. It requires a valid hardware configuration download from the host RX7i CPU (via Proficy Machine Edition / Logic Developer PLC) to initialize and join the network.



Maintenance & Troubleshooting

  • Diagnostic Indicators: Monitor front-panel LED status indicators for power, module health, and network ring activity.
  • Link Loss Troubleshooting: If communication drops across the ring, verify fiber continuity, check for tight cable bends, and clean LC optical connector tips with approved cleaning tools.
  • Firmware & Revision Management: Ensure that replacement modules match the system project revision (-ED or compatible equivalent) to avoid hardware configuration mismatch faults in the CPU fault table.



Safety & Handling

  • Power Isolation: Always disconnect and lock out main rack power before installing or removing the module.
  • Optical Safety: Avoid direct eye exposure to active LC fiber-optic transmitter ports or un-terminated live fiber cables.
  • ESD Protection: Always wear a properly grounded anti-static wrist strap when handling the circuit board.
