Description
🔹 Product Overview
The GE IS215VCMIH2C is a VME Communications Interface (VCMI) board used in the GE Mark VI Speedtronic turbine control system. It functions as a VME bus master and provides the communication interface between the main controller, I/O boards, and the IONet control network. The H2 version provides three IONet 10Base2 Ethernet ports, supporting R, S, and T communication channels for simplex and TMR system configurations.
The board uses a 32-bit processor architecture with dual-port memory and includes an RS-232C serial interface. It also manages rack board identification and communication between VME-based control and I/O hardware.
🔧 Key Features
• GE Mark VI VCMI Controller Board
• Model: IS215VCMIH2C
• Functional abbreviation: VCMI
• 6U VME board format
• VME bus master functionality
• Three IONet 10Base2 Ethernet ports
• R / S / T communication channels for TMR architectures
• RS-232C serial communication port
• 32-bit processor architecture
• Dual-port memory
• Front-panel Run, Fail, Status, Reset, and network indicators
• Designed for GE Speedtronic turbine control applications
🔑 Product Keywords
IS215VCMIH2C, VCMI, GE IS215VCMIH2C, GE Mark VI VCMI, GE VME Bus Master Controller, GE VME Communications Interface, Mark VI Communication Board, GE Turbine Control Module.
🔗 Product Keyword Link: IS215VCMIH2C GE VCMI Module
📋 Product Datasheet
| Parameter | Value |
|---|---|
| Brand | General Electric (GE) |
| Model | IS215VCMIH2C |
| Series | Mark VI Speedtronic |
| Product Name | VME Bus Master Controller / VCMI Board |
| Functional Abbreviation | VCMI |
| Processor | 32-bit architecture / TMS320C32 |
| Communication | 3 × IONet 10Base2 + 1 × RS-232C |
| Board Format | 6U VME |
| Origin | USA |
| Power | +5 VDC operating supply |
⚙️ Application
The IS215VCMIH2C serves as a central communication interface within compatible GE Mark VI control racks. It manages VME bus communication and provides the connection between the controller and I/O boards while interfacing with the IONet system control network. In TMR configurations, its three IONet ports can support the R, S, and T communication channels.
🛠️ Installation Notes
Before replacement, verify the complete IS215VCMIH2C part number, hardware revision, Mark VI rack configuration, VME backplane compatibility, and IONet architecture. The H2 version is specifically associated with three IONet ports, so the installed communication configuration should be checked before substituting another VCMI revision.
📦 Condition
The exact commercial condition should be confirmed from the supplied item and seller listing. Technical specifications above describe the IS215VCMIH2C model rather than guaranteeing the condition of a particular physical unit.
