Description
1. Product Description
The GE IS220PRTDH1BC, associated with part number 336A5026ADP13, is a Resistance Temperature Detector (RTD) input module for GE Speedtronic Mark VIe turbine control systems. It acquires temperature signals from compatible RTD sensors and passes the processed measurements to the control system for equipment monitoring, alarms, and control functions. Typical applications include gas and steam turbines, generators, bearings, and lubrication systems. The module is designed to work with a compatible RTD terminal board. Confirm the complete model suffix, terminal board pairing, and system revision before replacement.
IS220PRTDH1BC 336A5026ADP13
2. Product Parameters and Datasheet
• Brand: General Electric (GE)
• Model: IS220PRTDH1BC
• Associated Part Number: 336A5026ADP13
• Series: Mark VIe / Speedtronic
• Product Name: RTD Input Module / I/O Pack
• Function: Resistance temperature signal acquisition and processing
• Input Type: Compatible RTD sensors; verify supported sensor curves in the system documentation
• Input Channels: Confirm the exact channel count from the hardware revision and applicable manual
• Nominal Supply Voltage: 28 V DC
• Maximum Supply Current: 0.24 A, based on the published PRTD family electrical ratings
• RTD Input Voltage: 0–4.2 V, per published PRTD family ratings
• RTD Input Current: 10 mA nominal, per published PRTD family ratings
• Communication: Mark VIe I/O network; confirm the exact network configuration
• Compatible Terminal Boards: Approved combinations include IS200TRTDH2D, IS200SRTDH1A, and IS200SRTDH2A for specified PRTD revisions; verify the exact suffix and installation requirements
• Place of Manufacture: Verify from the product label
• Product Status: Confirm with seller; new, surplus, open-box, or used condition may vary
• Dimensions: Verify by hardware revision
• Weight: Verify by hardware revision and packaging
• Country of Origin: Check nameplate or shipping documents
• Power Requirements: 28 V DC nominal; verify the applicable equipment manual
• Discontinued: Current lifecycle status not confirmed
