1. Product Description
The GE Multilin SR469-P5-HI-A20-E is a motor management and protection relay designed to monitor, protect, and control industrial motors. Part of the 469 series, it integrates electrical protection, motor thermal monitoring, status supervision, and programmable control functions in a panel-mounted unit. It is suitable for industrial facilities, power distribution systems, and motor-driven equipment requiring comprehensive protection.
The model configuration includes 5 A phase current transformer (CT) inputs, high-range control power, four 4–20 mA analog outputs, and an enhanced front panel with an LCD display. Communication and configuration are supported through the relay’s serial interfaces and compatible setup software. Protection settings must be configured to match the motor nameplate, CT ratios, starting characteristics, and system protection coordination requirements.
SR469-P5-HI-A20-E
2. Product Parameters — Datasheet
Brand: GE Multilin
Model: SR469-P5-HI-A20-E
Product Series: Multilin 469 Motor Management Relay
Product Name: Motor Management and Protection Relay
Product Type: Digital Motor Protection Relay
Phase CT Secondary Rating: 5 A
Control Power — AC: 70–265 VAC, 48–62 Hz
Control Power — DC: 90–300 VDC
Analog Outputs: Four 4–20 mA outputs
Display: Enhanced front panel with larger LCD
Communication Interfaces: RS-232 and RS-485 serial interfaces
Communication Protocol: Modbus RTU support; confirm configuration and system settings
Protection Functions: Motor thermal overload, phase current monitoring, and other configurable motor protection functions
Mounting: Panel mounting in compatible SR469 case; rack installation with suitable hardware
Dimensions: Approx. 252 × 216 × 224 mm reported for the cased product; verify installation drawing
Weight: Approximately 7.3–7.7 kg, depending on packaging and configuration
Place of Manufacture: Not confirmed for every unit
Country of Origin: Canada is marked on documented units; verify the specific relay label
Product Status: New surplus, used, or refurbished availability depends on supplier inventory
Discontinued: Legacy product; confirm current support and spare-parts availability
Compatibility: Verify the relay order code, case, CT inputs, control power, wiring, and protection settings before replacement
3. Recommended GE Multilin Models
The following models are related motor and generator protection relays for comparison and spare-parts sourcing. They are not all direct replacements; select according to CT rating, control voltage, output configuration, and protection requirements.
- GE Multilin SR469-P5-HI-A20 — 469 motor management relay with 5 A CT inputs and high-range control power.
- GE Multilin SR469-P5-HI-A20-E-H — Enhanced-display version with additional conformal coating for harsh environments.
- GE Multilin SR469-P5-HI-A20-T — Related 469 configuration with Ethernet communication.
- GE Multilin SR469-P5-LO-A20 — 469 relay with low-range control power and 4–20 mA analog outputs.
- GE Multilin SR469-P5-LO-A20-E — Enhanced-display variant with low-range control power.
- GE Multilin SR469-P1-HI-A1-E — 469 relay with 1 A CT inputs and enhanced display.
- GE Multilin SR469-P1-HI-A1-E-H — Related 469 configuration with conformal coating.
- GE Multilin 469-P5-HI-A20-E — Equivalent order-code designation commonly used for the enhanced 5 A CT model.
- GE Multilin 469-P5-HI-A20-E-H — Enhanced 469 relay option for applications requiring conformal coating.
- GE Multilin 469-P5-HI-A20-T — 469 motor management configuration with Ethernet.
- GE Multilin 469-P1-HI-A20-E — Related 469 variant; confirm the exact CT and analog-output configuration.
- GE Multilin 469-P5-LO-A20-E — Related 469 relay with low-range control power.
- GE Multilin SR469-CASE — Compatible case assembly category; verify the exact case part number.
- GE Multilin 489-P5-HI-A20-E — Generator management relay for generator protection applications.
- GE Multilin 489-P5-HI-A20 — Related generator protection relay with high-range control power.
Before ordering, match the complete model SR469-P5-HI-A20-E and confirm the case, control-power range, CT secondary rating, and analog-output configuration. Protection settings should be checked by qualified personnel before the relay is returned to service.
