Product Description
The GE Multilin SR469-P5-HI-A20 is a microprocessor-based motor protection and management relay designed to monitor and protect medium- and large-sized AC motors. It combines motor protection, operating measurements, fault diagnostics, thermal modeling, and programmable control functions in a draw-out relay assembly for industrial motor control centers and electrical distribution systems.
The relay supports 5 A phase current transformer (CT) inputs, a wide-range control power supply, and four 4–20 mA analog outputs. Protection capabilities include thermal overload, locked rotor, phase imbalance, ground fault, and start supervision, depending on configuration. Communication and system integration should be verified against the installed firmware and application requirements.
SR469-P5-HI-A20
Product Parameters and Datasheet
Brand: GE Multilin
Model: SR469-P5-HI-A20
Series: 469 Motor Management Relay
Product Name: Motor Protection and Management Relay
Place of Manufacture: Canada (verify the individual unit nameplate)
Product Status: Legacy product; confirm availability and condition with the seller
Phase CT Input: 5 A secondary
Control Power: 90–300 VDC or 70–265 VAC, 48–62 Hz
Analog Outputs: Four 4–20 mA outputs
Communication: Serial communication; verify protocol and interface configuration
Mounting: Panel or compatible 19-inch rack installation
Protection Functions: Motor thermal overload, locked rotor, phase-related protection, ground-fault protection, and start supervision; exact functions depend on configuration
Dimensions: Verify against the applicable installation manual and enclosure
Weight: Verify against the supplied unit and packaging
Country of Origin: Verify on the unit nameplate
Power Requirements: 90–300 VDC or 70–265 VAC, 48–62 Hz
Discontinued: Legacy product; confirm current lifecycle and replacement options before ordering
Compatibility Note: Confirm the full model code, CT ratings, control power, wiring, relay settings, communication requirements, and case compatibility before replacing an installed unit.
Recommended GE Multilin Models
1. SR469-P1-HI-A20 — 469 relay variant with 1 A phase CT inputs; verify the complete order code.
2. SR469-P5-LO-A20 — 469 variant with 5 A phase CT inputs and a different control-power range; verify suffix details.
3. SR469-P5-HI-A1 — 469 variant with 5 A phase CT inputs and 0–1 mA analog outputs.
4. SR469-P5-HI-A20-E — 469 variant with enhanced front-panel options; confirm the full configuration.
5. SR469-P5-HI-A20-E-H — enhanced-front-panel variant with conformal coating for harsh environments.
6. SR469-P1-HI-A1 — 469 variant with 1 A phase CT inputs and 0–1 mA analog outputs; verify ordering code.
7. SR469-P1-LO-A20 — 469 variant with 1 A phase CT inputs and a different control-power range.
8. SR469-P5-LO-A1 — 469 variant with 5 A phase CT inputs and 0–1 mA analog outputs.
9. SR469-P1-HI-A20-E — 469 variant with 1 A phase CT inputs and enhanced front-panel options.
10. SR469-P5-HI-A20-T — related 469 ordering variant; verify the suffix and communication options before selection.
11. SR469-P5-HI-A20-D — related 469 ordering variant; confirm the exact option code before ordering.
12. SR469-P5-HI-A20-H — 469 variant associated with harsh-environment coating options; verify the complete order code.
13. 369-HI-R-M-0-0 — GE Multilin motor management relay for related motor-protection applications.
14. 239 Motor Protection Relay — GE Multilin motor protection option for applications requiring a different relay platform.
15. 469 Motor Management Relay — the broader GE Multilin product family for comparing protection and configuration requirements.
These models are related product-family references, not guaranteed drop-in replacements. Check the complete nameplate code and application documentation before purchasing or substituting a relay.
