Product Description
The Honeywell CC-TDOB01 is a Series C Input/Output Termination Assembly (IOTA) designed for the Experion PKS distributed control system. It provides the field-wiring interface for the compatible CC-PDOB01 digital output module, connecting controller output signals to discrete field devices such as solenoid valves, indicator lamps, and auxiliary relays. The assembly supports 24 VDC digital output applications and is intended for simplex, non-redundant configurations. For redundant applications, the compatible CC-TDOB11 assembly should be evaluated. The CC-TDOB01 is a termination assembly, not a standalone electronic output module.
CC-TDOB01
Product Parameters and Datasheet
Brand: Honeywell
Model: CC-TDOB01
Part Number: 51308371-175
Series: Experion PKS Series C I/O
Product Name: Digital Output Termination Assembly (IOTA)
Product Type: Digital Output Field-Wiring Assembly
Compatible I/O Module: CC-PDOB01
Channel Capacity: 32 digital output channels, subject to the specified system configuration
Output Signal: 24 VDC digital output through the compatible I/O module
Output Type: Source-type output configuration
Maximum Output Current: Up to 0.5 A per channel under specified conditions
Redundancy: Simplex / non-redundant
Redundant IOTA Option: CC-TDOB11
Dimensions: Approx. 121 × 188 × 32 mm; verify against the applicable installation drawing
Weight: Approximately 0.25 kg; confirm for the supplied unit
Place of Manufacture: Not confirmed for the individual unit
Product Status: Confirm availability and condition with supplier
Country of Origin: Verify the product label and shipping documents
Power Requirements: External 24 VDC field supply; verify wiring polarity and system specifications
Discontinued: Confirm current lifecycle status with supplier
Recommended Honeywell Models
1. CC-PDOB01 – Compatible digital output I/O module for the CC-TDOB01 assembly.
2. CC-TDOB11 – Redundant termination assembly option for supported digital output configurations.
3. CC-TDOR01 – Termination assembly for compatible relay-type digital outputs.
4. CC-TDOR11 – Redundant termination assembly for supported relay output configurations.
5. CC-PDOR01 – Digital output module; verify the exact hardware configuration.
6. CC-PDIL01 – 32-channel, 24 VDC digital input module.
7. CC-PDIS01 – Digital input module with sequence-of-events functionality.
8. CC-PAON01 – 16-channel analog output module without HART.
9. CC-PAOX01 – Analog output module for supported Series C configurations.
10. CC-PAIH01 – Analog input module with HART support.
11. CC-PAIX01 – High-level analog input module.
12. CC-PUIO01 – Universal input/output module for supported configurations.
13. CC-PUIO31 – Universal input/output module for compatible Series C systems.
14. CC-PCNT01 – C300 controller module for Experion PKS.
15. CC-TDIL01 – Termination assembly for compatible digital input configurations.
Compatibility Note: Confirm the CC-PDOB01 pairing, terminal assignments, external field-supply polarity, load current, and redundancy requirements before installation. Related models listed above are not all direct replacements.
