Description
The ICS Triplex T9402 is a high-reliability digital input component designed for the Regent system architecture. Engineered to provide fault-tolerant performance in safety-critical environments, this module interfaces field signals with the central processor, ensuring that every digital input is accurately recorded and processed. The T9402 is built for industrial durability, featuring advanced diagnostics that help identify field-side or internal faults before they can impact plant safety or production uptime.
Discover more professional automation hardware at our ICS TRIPLEX T9402 specialized component page.
Technical Datasheet
Product Identification
- Model Number: T9402
- Series: Trusted™ Regent
- Manufacturer: ICS Triplex (Rockwell Automation)
- Module Type: Digital Input Module
Physical Characteristics
- Dimensions: 280 mm x 25 mm x 210 mm
- Weight: 1.1 kg
- Country of Origin: United Kingdom / USA
Operational Specifications
- Input Channels: 32 Channels
- Nominal Voltage: 24V DC
- Input Threshold: 11V to 15V DC (Standard Logic)
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -25°C to 70°C
ICS TRIPLEX T9402
ICS TRIPLEX T9402
ICS TRIPLEX T9402
ICS TRIPLEX T9402
Application Fields
The T9402 is widely implemented in industries where safety and high availability are non-negotiable:
- Petrochemical Refineries: Monitoring critical valve positions and pressure switches.
- Marine & Subsea: Integration into shipboard control systems and offshore drilling safety logic.
- Power Plants: Handling digital signals for secondary protection circuits and auxiliary equipment.
- Manufacturing: Serving as the safety interface for large-scale automated assembly lines.
Product Usage Instructions
- Hardware Inspection: Before installation, ensure the module version is compatible with your existing Regent chassis and processor firmware.
- Installation: Slide the module into its dedicated slot. Ensure the connectors on the rear of the module align perfectly with the backplane pins to avoid physical damage.
- Field Connection: Utilize the appropriate termination blocks to connect field wiring. It is recommended to use twisted-pair cabling to minimize noise interference on the 24V inputs.
- System Initialization: Once powered, the system will perform a self-check. Verify that the “Module OK” LED is illuminated. Use the system’s engineering workstation to map the 32 input channels to your logic.
- Routine Maintenance: Check terminal connections annually for tightness and ensure the module’s cooling path remains free of industrial dust or debris.
Common Questions & Answers
Q: Does the T9402 support channel-to-channel isolation? A: The T9402 features group isolation and robust protection against field surges, though specific isolation levels depend on the backplane and termination unit used.
Q: Can I replace a T9402 module while the system is running? A: Yes, the Regent architecture generally supports hot-swapping of I/O modules, but always verify your specific system configuration and safety protocols before performing live maintenance.
Q: What is the primary difference between the T9402 and the T8403? A: The T9402 belongs to the Regent series, whereas the T8403 is part of the Trusted™ TMR (Triple Modular Redundant) series. They serve different system backplanes and architectures.
Similar Model Recommendations
- ICS Triplex T9431
- ICS Triplex T9451
- ICS Triplex T9110
- ICS Triplex T9481
- ICS Triplex T9310
