Description
The MOOG RDC2 is a high-performance, ruggedized digital controller engineered for demanding industrial and mobile applications. It combines advanced computational power with a durable design, enabling precise closed-loop control of hydraulic and electric actuators in environments characterized by extreme temperatures, vibration, and moisture.
Technical Parameters
- Model: RDC2 (Rugged Digital Controller)
- Processor: 32-bit RISC Architecture with Floating Point Unit
- Memory: 128 MB RAM / 32 MB Flash EEPROM
- Supply Voltage: 24V DC nominal (18V to 36V range)
- Communication: Ethernet (10/100 Mbit/s), CANbus, and RS-232/485 interfaces
- I/O Configuration: Configurable digital and high-resolution analog channels
Product Specifications
- Ingress Protection: IP67 rated (fully sealed against dust and water)
- Operating Temp: -40°C to +70°C (-40°F to +158°F)
- Shock Resistance: 50g (3ms, 6 directions)
- Vibration Resistance: 30g (10 Hz to 2 kHz)
- Mounting: Direct surface mount or DIN rail via adapter
- Housing: Robust aluminum enclosure with chemical-resistant coating
Application Areas
- Mobile hydraulic machinery and construction equipment
- Oil and gas downhole drilling and exploration tools
- Aerospace and defense flight simulation systems
- Marine vessel motion control and stabilization
- Heavy industrial material handling in harsh environments
Product Q&A
- Q: What makes the RDC2 “rugged” compared to standard controllers?
- A: Its IP67 rating and specialized internal components allow it to operate in extreme cold, heat, and high-vibration areas without an external protective cabinet.
- Q: Can this controller be programmed with standard tools?
- A: Yes, it typically uses the Moog Application Software Suite (MASS) based on the IEC 61131-3 standard.
- Q: Does it support real-time industrial networks?
- A: It is designed for high-speed data exchange via EtherCAT or CANopen, depending on the specific firmware configuration.
