PIONEER MAGNETICS PM3398B-6P-1-3P-E | 80026-172-23 | SWITCHING POWER SUPPLY MODULE
PIONEER MAGNETICS PM3398B-6P-1-3P-E | 80026-172-23 | SWITCHING POWER SUPPLY MODULE - Image 2
PIONEER MAGNETICS PM3398B-6P-1-3P-E | 80026-172-23 | SWITCHING POWER SUPPLY MODULE - Image 3

PIONEER MAGNETICS PM3398B-6P-1-3P-E | 80026-172-23 | SWITCHING POWER SUPPLY MODULE

Original price was: $10,000.00.Current price is: $1,050.00.

Product NO：PM3398B-6P-1-3P-E  80026-172-23

Brand: PIONEER MAGNETICS

Delivery time:  In stock

Product status:   Brandnew

Product situation: one year warranty, Origin of Manufacture

Add to quote
Category: Tags:
Felix Sales Manager
[email protected] +86 138 2210 1417 8613822101417
WhatsApp
QR
Chat Now
There are still many products that have not been released yet. If you have any products that you cannot find, you can ask me for a quote! Reminder: The product images published on this website are not actual real products and are for reference only!

Description

Hardware Specifications

  • Manufacturer: Pioneer Magnetics
  • Model / Series: PM3398B (PM3398 Series High-Efficiency Switch-Mode Power Supply)
  • Part / Ordering Number: 80026-172-23 (Variant with specialized “-6P-/-3P-” output or control configuration)
  • Module Type: Multi-Output Industrial Switch-Mode Power Supply (SMPS)
  • AC Input Voltage Range: 100 to 240 VAC wide-range industrial input
  • Power Topology: High-frequency switching design optimized for high power density and reliable continuous output
  • Mounting Format: Enclosed chassis-mount unit designed for heavy industrial control cabinets and automation racks
  • Application Environment: Heavy industrial process controls, large automated systems, and high-reliability electronics



Installation & Guidelines

  • Mounting Security: Secure the chassis firmly to a grounded metal subpanel inside your control cabinet using all mounting holes to ensure structural rigidity against machinery vibration.
  • Ventilation & Clearances: Maintain unobstructed airflow around the unit’s cooling slots and heat sinks. Do not block natural convection paths or forced-air intake zones.
  • Input Wiring: Connect AC line, neutral, and earth ground securely to the designated input terminal block, verifying correct voltage range before powering up.
  • Output Load Balancing: Ensure total current draw across all output channels stays within the rated specifications to prevent thermal overload.



Maintenance & Troubleshooting

  • Visual & Thermal Checks: Periodically check cooling vents for dust or debris accumulation; clear blockages using dry, oil-free compressed air during scheduled plant shutdowns.
  • Terminal Tightness: Inspect input and output terminal screws regularly to prevent loose connections caused by continuous industrial vibration.
  • Output Voltage Verification: If the system experiences power loss or faults, measure output voltage rails at the terminal blocks using a digital multimeter to confirm regulation.



Safety & Handling

  • Capacitor Discharge Time: High-voltage internal DC bus capacitors retain dangerous electrical charges even after AC input power is removed. Allow a minimum of 5 minutes for internal discharge before servicing.
  • Power Isolation: Always disconnect and lock out main electrical feed lines before installing, wiring, or removing the power supply unit.
  • ESD & Electrical Protection: Handle the unit carefully, observing standard electrical safety precautions to prevent accidental short circuits or shock hazards.
