Description
Product Specifications
| Feature | Details |
|---|---|
| Brand | Rolls-Royce (Marine Division) |
| Model Number | MPCF1-10.4″ MARITIME PANEL COMPUTER |
| Revision | Rev D |
| Location Assignment | Starboard (STBD) Wing |
| Country of Origin | Norway / United Kingdom |
| Weight | Approx. 4.8 kg |
| Dimensions | 285mm x 220mm x 75mm (Panel Cutout Compatible) |
| Display Size | 10.4-inch High-Brightness TFT |
| Operating Voltage | 24V DC (Marine Grade) |
The ROLLS-ROYCE MPCF1-10.4″ Rev D is a ruggedized maritime workstation specifically configured for starboard wing console integration. Designed to provide real-time data response and propulsion visualization, this maritime panel computer features a high-visibility display and specialized hardware architecture to withstand extreme vibration, salt mist, and temperature fluctuations common in bridge-wing environments.
Q&A: Product Common Issues & Solutions
Q: Why is the display dim or flickering during nighttime operations? A: This is often related to the backlight inverter or a faulty dimming control signal from the bridge central system. Check the brightness potentiometer and ensure the “Night Mode” voltage signal is within the specified range for Rev D hardware.
Q: Can a Rev D unit be interchanged with an earlier Rev B or C unit? A: While physically similar, Rev D often includes updated processor boards or updated LVDS connections. You must verify that the existing software image and mounting brackets are compatible with the Revision D hardware interface before installation.
Q: What causes the touch interface or physical buttons to become unresponsive? A: Exposure to heavy sea spray can lead to salt buildup around the bezel. Clean the panel with an approved marine electronic cleaner. If the issue persists, the internal communication controller may have suffered from moisture ingress through the rear ventilation ports.
