1. Product Description
The Toshiba 2N3A3120-D is identified in supplier listings as an IGBT power semiconductor module intended for high-power switching and energy-conversion applications. It may be used in industrial motor drives, inverters, and power-conversion equipment. The listed electrical ratings are 1200 V and 320 A, with a reported maximum power dissipation of 1900 W. These figures should be confirmed against the module’s original datasheet and markings before design or replacement, as a reliable manufacturer datasheet for this exact part number was not verified.
2N3A3120-D
2. Product Parameters and Datasheet
– Brand: Toshiba
– Model: 2N3A3120-D
– Series: Power Semiconductor Module; exact series unverified
– Product Name: IGBT Power Module (supplier-listed classification)
– Semiconductor Type: IGBT module, as described by supplier listings
– Reported Rated Voltage: 1200 V
– Reported Rated Current: 320 A
– Reported Maximum Power Dissipation: 1900 W
– Package Type: Power module; confirm package and terminal layout
– Typical Applications: Industrial inverters, motor drives, and power converters
– Gate Drive Requirements: Verify from the original datasheet
– Cooling Requirements: Verify mounting surface, thermal interface, and cooling method
– Dimensions: Not verified; check physical measurements and original documentation
– Weight: Not verified
– Place of Manufacture / Country of Origin: Verify from the product label and shipping documentation
– Product Status: Availability and condition depend on supplier stock
– Discontinued: Not confirmed
3. Recommended Toshiba Models
– 2N3A3120-C — Related Toshiba part number; confirm electrical and mechanical compatibility.
– 2N3A3110-C — Toshiba part number listed in historical component references; exact function must be verified.
– 2N3A8216-A — Related Toshiba part number; not confirmed as a direct substitute.
– 2N3N0133-A — Toshiba industrial component part number; verify device type before selection.
– 2N3N0041-D — Toshiba component part number; verify its function and ratings.
– 2N3N0068-C — Toshiba component part number; verify its function and ratings.
– 2N3A3120-D — Exact model for replacement identification.
– Toshiba IGBT modules — Select only after matching voltage, current, switching characteristics, and package.
– Toshiba high-power semiconductor modules — Verify device topology and pinout.
– Toshiba industrial power devices — Match the original electrical and thermal specifications.
– Toshiba diode modules — Consider only if the original circuit requires a diode module.
– Toshiba thyristor modules — Consider only if the original circuit requires a thyristor module.
– Toshiba power switching modules — Verify gate-drive and protection requirements.
– Toshiba inverter components — Match the original equipment model and circuit design.
– Toshiba motor-drive semiconductor components — Confirm manufacturer documentation before substitution.
Important: Do not replace this module based only on voltage and current ratings. Verify the original datasheet, internal circuit topology, pinout, switching characteristics, and thermal requirements before installation.
