Description
The TRICONEX T8800C PD8800 PCB130100 is identified in industrial automation listings as a processor/control module associated with the Triconex safety instrumented system platform. It is intended for high-availability process control and safety applications where fault tolerance and continuous operation are important.
The T8800C designation is also associated with the PD8800 platform and RISC processor architecture in industrial automation references. Because published third-party specifications for this part are inconsistent, exact electrical and mechanical values should be verified against the nameplate and system documentation before replacement.
🔧 Control Function
The module is used within a safety-oriented control architecture to execute control processing and exchange data with the associated system hardware. Triconex systems are designed around fault-tolerant architectures for critical process applications.
🏭 Typical Applications
• Safety Instrumented Systems (SIS)
• Emergency shutdown systems
• Petrochemical plants
• Oil and gas facilities
• Power generation
• Chemical processing
• Turbine protection systems
• Critical process automation
📋 Product Datasheet
| Parameter | Specification |
|---|---|
| Manufacturer | TRICONEX |
| Model | T8800C |
| Module / System | PD8800 |
| PCB Number | PCB130100 |
| Product Type | RISC Processor / Control Module* |
| Application | Safety Instrumented System |
| Architecture | High-Availability / Fault-Tolerant |
| Processor Architecture | RISC* |
| Operating Voltage | 24 VDC* |
| Processing Function | Safety Control & System Processing |
| System Integration | Triconex Safety Control Platform |
| Communication | System-Dependent |
| Installation | Industrial Control System |
| Operating Temperature | -40°C to +85°C* |
| Dimensions | Approx. 167 × 148 × 55 mm* |
| Weight | Approx. 0.6 kg* |
| Mounting | System Chassis / Control Cabinet |
| Country of Origin | USA* |
| Configuration | Application-Dependent |
*Several reseller references describe PCB130100 as a digital I/O module, while other industrial listings identify the same T8800C PD8800 PCB130100 as a RISC processor. These conflicting descriptions make it important to verify the exact hardware label and system configuration before publishing electrical specifications or using it as a replacement.
⚡ Key Features
• Designed for Triconex safety-control applications
• High-availability control architecture
• RISC-based processing identification in published listings
• Suitable for critical process environments
• Modular system architecture
• Designed for industrial continuous-operation systems
• Suitable for maintenance and replacement inventory
🔌 System Integration
The T8800C is intended to operate as part of a larger Triconex control architecture rather than as a standalone PLC. System configuration depends on the installed chassis, processor arrangement, I/O modules, communication hardware, firmware, and application logic.
Before commissioning a replacement, compare the PCB number, hardware revision, firmware, connector arrangement, and existing system configuration.
🛠️ Installation Notes
Before installation, verify T8800C / PD8800 / PCB130100 against the original module label and cabinet documentation.
Disconnect power according to site procedures before removing the existing hardware. Inspect connectors, backplane contacts, grounding, and mounting points before installation.
After replacement, verify processor status, system diagnostics, communication, application loading, and safety-system fault indications.
⚙️ Commissioning Checklist
• Verify complete part number
• Confirm PCB revision
• Check system compatibility
• Verify power supply
• Inspect connectors
• Confirm chassis position
• Check processor diagnostics
• Verify system communication
• Confirm application configuration
• Perform required safety validation
⚠️ Compatibility Notice
The TRICONEX T8800C PD8800 PCB130100 should not be treated as a generic PLC module. It is associated with a specialized safety-control platform, and replacement compatibility depends on the complete system configuration.
For a safety-related replacement, always verify the hardware revision, firmware, system architecture, and approved configuration before returning the system to service.
📦 Product Identification
Brand: TRICONEX
Model: T8800C
System: PD8800
PCB: PCB130100
Product Type: RISC Processor / Control Module
Application: Safety Instrumented System
Function: Safety Control & Processing
Industry: Oil & Gas / Power / Process Automation
