Description
The VIBRO-METER MPC4 (200-510-076-114) is a sophisticated Machinery Protection Card designed for the VM600 series rack systems. This module is the core intelligence for monitoring critical rotating machinery, such as turbines, compressors, and pumps. It processes signals from various sensors—including proximity probes, seismic sensors, and accelerometers—to provide real-time vibration monitoring, machine health analysis, and automated protection via trip relays, ensuring safe operations in high-stakes industrial environments.
⚙️ Technical Specifications
- Module Type: MPC4 Machinery Protection Card
- Part Number: 200-510-076-114
- Input Channels: 4 dynamic inputs (configurable for sensors)
- Signal Processing: Integrated signal filtering, integration, and peak detection
- Compatibility: Fully compatible with VM600 ABE04x system racks
- Data Interface: High-speed internal bus for communication with CPUs
- Measurement Ranges: Fully programmable via configuration software
- Status Indicators: Front-panel LEDs for channel health and alarm state
- Operating Temperature: -20°C to +65°C
- Safety Integrity: Designed for high-availability machinery shutdown applications
📋 Recommended VM600 Series Components
- IOC4T: Input/Output Termination Card (Essential for MPC4 field wiring)
- CPUM: Central Processing Unit and Communication Module
- RPS6U: 200-582-915-032 Rack Power Supply Module
- XMC16: Extended Monitoring Card for supplemental sensing
- RCM: Relay Card Module for expanded alarm distribution
- AMC8: 8-Channel Analog Monitoring Card
- ABE040: Standard 19-inch 6U System Rack
- ABE042: 19-inch 6U Rack with integrated wiring features
- ASPS: Auxiliary Sensor Power Supply
- VM600 Configuration Software: For setup and diagnostics of MPC4 cards
