WOODWARD 5501-380 | Precision Engine & Turbine Digital Control Module

Description

• The WOODWARD 5501-380 is a high-performance digital control assembly designed for the precise management of industrial engines and turbines. Part of the renowned MicroNet and 505 series families, this module integrates advanced microprocessor technology to handle complex governing, system logic, and protection parameters. It is engineered for environments where reliability and millisecond-level responsiveness are non-negotiable, ensuring optimal fuel efficiency and mechanical longevity.


  Technical Specifications (Datasheet)

  Model: 5501-380 Manufacturer: Woodward Series: MicroNet / 505 Control Systems Input Voltage: 18-36 VDC Operating Temperature: -40°C to +70°C Communication Ports: RS-232, RS-422, Ethernet (depending on carrier) Dimensions: 20.3 cm x 15.2 cm x 3.8 cm (approximate) Weight: 0.85 kg (1.87 lbs) Country of Origin: USA

  Application Fields

  This module is primarily utilized in heavy industrial sectors where synchronized power and mechanical stability are critical. Key applications include:

  • Power Generation: Governing steam and gas turbines for grid synchronization.
  • Oil & Gas: Controlling compressors and pumps in pipeline stations.
  • Marine Propulsion: Managing main engine speeds and load sharing.
  • Chemical Processing: Regulating mechanical drive turbines for consistent plant operations.

  Product Usage Instructions

  1. Pre-Installation Inspection: Ensure the power supply is disconnected and verify that the module hardware revision matches your system requirements.
  2. Mounting: Secure the module into the designated chassis slot. Use ESD (Electrostatic Discharge) wrist straps to prevent internal circuit damage.
  3. Wiring: Connect the I/O terminals according to the specific wiring diagram for your turbine model. Ensure all shielded cables are properly grounded to mitigate EMI.
  4. Configuration: Use Woodward’s proprietary software (such as GAP™ or Watch Window) to load the application-specific control logic.
  5. Calibration: Calibrate the actuator outputs and sensor inputs to ensure the digital signal accurately reflects physical parameters like RPM and pressure.

  Frequently Asked Questions (Q&A)

  Q: Can the 5501-380 be hot-swapped during operation? A: No. It is highly recommended to power down the control rack before removing or inserting the module to prevent electrical surges or logic errors.

  Q: How do I identify a hardware failure in the module? A: Check the onboard LED status indicators. A steady red “Fault” light or a failure to communicate via the service port usually indicates a hardware malfunction.

  Q: Is this module compatible with older 505 series systems? A: Compatibility depends on the firmware version and the carrier card used. Please consult the specific system manual for cross-generation integration.

  Q: Where can I find genuine replacement parts for this model? A: For authentic components and expert support, visit https://www.newplcdcs.com to find the WOODWARD 5501-380 and related hardware.
