The Yaskawa CPS-150F is a dedicated control power supply used in YASNAC/MOTOMAN robotic control systems, including certain XRC and NX100 controller configurations. It supplies DC power to controller electronics and associated control circuits. The unit is designed for rack installation in the intended controller cabinet and features front-panel status indicators. Before replacement, verify the complete model number, connector layout, controller type, and electrical ratings against the original unit.
YASKAWA CPS-150F
Product Parameters and Datasheet
| Parameter | Details |
| Brand | Yaskawa |
| Model | CPS-150F |
| Series | YASNAC / MOTOMAN |
| Product Name | Robot Controller Control Power Supply |
| Product Type | Rack-mounted power supply module |
| Application | Compatible XRC and NX100 controller configurations; verify exact system |
| Input Voltage | 200–230 VAC, nominal range commonly specified |
| Input Frequency | 50/60 Hz |
| Input Current | Approximately 2.1 A |
| DC Outputs | +5 VDC and +24 VDC |
| Output Ratings | Commonly listed as +5 VDC, 10 A and +24 VDC, 4 A; confirm nameplate |
| Indicators | SOURCE / power and output-status indicators, depending on revision |
| Mounting | Controller rack installation |
| Dimensions | Approximately 180 × 60 × 270 mm; verify before installation |
| Weight | Approximately 2.0–2.27 kg, excluding packaging |
| Place of Manufacture / Origin | Verify from the unit label |
| Product Status | Confirm actual stock condition |
| Discontinued | Listed as discontinued by manufacturer; confirm current service availability |
