WOODWARD PEAK200-HVAC 8200-1501 | Steam Turbine Controller

Description

WOODWARD PEAK200-HVAC 8200-1501 | Steam Turbine Controller Datasheet & Guide

📝 Product Introduction

The Woodward PEAK200-HVAC (Part Number 8200-1501) is an advanced, high-reliability digital controller designed specifically for the operation and protection of small single-valve or single-valve-rack industrial steam turbines, turbo-expanders, and industrial fans. Engineered as a cost-effective, field-configurable solution, it features an integrated graphical operator control panel, advanced dynamic PID algorithms, and comprehensive monitoring capabilities to ensure robust steady-state stability and fast transient responses in critical industrial applications such as oil, gas, petrochemical, and power generation.

📊 Product Datasheet & Parameters

• 1. Manufacturer: Woodward
• 1. Product Model: PEAK200 (8200-1501)
• 1. Controller Type: High-Voltage Bulkhead-Mounted Steam Turbine Controller
• 1. Input Power Supply: 88–264 VAC / 90–150 VDC High Voltage
• 1. Mounting Style: Bulkhead Mount
• 1. Dimensions: 38 cm x 36 cm x 10 cm
• 1. Weight: 2.0 kg
• 1. Country of Origin: USA
• 1. Operating Temperature: -20°C to +60°C
• 1. Communication: Ethernet and Serial (Modbus TCP/RTU)

⚙️ Product User Instructions

• Verify that the high-voltage power supply is entirely switched off and locked out before performing installation or wiring tasks.
• Securely mount the bulkhead unit onto a flat, stable surface within a protective control cabinet, ensuring adequate clearance for ventilation.
• Connect the high-voltage power source to the designated input terminals while strictly observing local electrical safety codes.
• Attach field sensors, actuators, and communication lines to their respective terminal blocks according to the wiring schematics.
• Power on the system, access the user-friendly graphical menu interface, and configure control parameters, speed setpoints, and safety limits before initiating turbine startup.

💡 Frequently Asked Questions (Q&A)

• Q: What is the main application of the Woodward 8200-1501 controller?
• A: It is primarily used for the precise speed and load control, monitoring, and overspeed protection of small industrial steam turbines and turbo-expanders.
• Q: Does this model support high-voltage power inputs?
• A: Yes, the 8200-1501 version is specifically configured for high-voltage applications, supporting 88–264 VAC or 90–150 VDC inputs.
• Q: Can the controller be configured directly on-site?
• A: Yes, it features an integrated graphical operator control panel and field-configurable software menus protected by secure password access.

🔌 Recommended Woodward Models & Series

• 1. Woodward Peak200 8200-1500 (Bulkhead Mount, Low Voltage)
• 1. Woodward Peak200 8200-1504 (Front Panel Mount, High Voltage)
• 1. Woodward 505 Digital Turbine Controller Series
• 1. Woodward MicroNet Safety Module Platform
• 1. Woodward Atlas Digital Control Platform
• 1. Woodward ProTech-SX Overspeed Protection System
• 1. Woodward TG-13 Mechanical-Hydraulic Governor
• 1. Woodward CPC II (Current-to-Pressure Valve Actuator Driver)
• 1. Woodward NetCon Distributed Control System
• 1. Woodward 723PLUS Digital Governor
