The GE IC697PWR720 is a Series 90-70 Power Supply Adapter Module designed to interface an external power source with the PLC rack backplane. It provides the required +5 VDC, +12 VDC, and -12 VDC backplane supply connections and supports orderly PLC power-up and shutdown signaling. The module occupies one rack slot and is designed for integration with GE Series 90-70 PLC systems. The documented maximum backplane current is 18 A at +5 VDC, 2 A at +12 VDC, and 1 A at -12 VDC.
IC697PWR720
📋 Product Datasheet
| Parameter | Value |
|---|---|
| Brand | GE |
| Model | IC697PWR720 |
| Series | Series 90-70 |
| Product Name | Power Supply Adapter Module |
| Product Type | PLC Power Supply Adapter |
| Place of Manufacture | USA |
| Condition / Status | New Surplus / Original |
| Dimensions | Approx. 13 × 7 × 4.5 cm |
| Weight | Approx. 0.8 kg |
| Power / Output | +5 VDC 18A, +12 VDC 2A, -12 VDC 1A |
🔧 Key Technical Features
• Single-slot rack installation
• +5 VDC backplane output: up to 18 A
• +12 VDC backplane output: up to 2 A
• -12 VDC backplane output: up to 1 A
• Nominal backplane voltages: +5.07 VDC, +12 VDC, and -12 VDC
• Supports VME standard C.1 architecture
• Provides power-monitoring and system reset/power-fail interface functions
❓ Common Questions & Answers
Q: What is the GE IC697PWR720?
A: It is a Power Supply Adapter Module for the GE Series 90-70 PLC system.
Q: Does the IC697PWR720 generate the main power by itself?
A: No. It interfaces an external power supply with the PLC rack and passes the required DC supply voltages to the backplane.
Q: How many rack slots does it occupy?
A: The module uses one rack slot.
Q: What are its maximum backplane current ratings?
A: +5 VDC at 18 A, +12 VDC at 2 A, and -12 VDC at 1 A.
Q: Is IC697PWR720 compatible with Series 90-70 PLC systems?
A: Yes. It was specifically designed for the Series 90-70 PLC architecture.
Q: What should be checked before installation?
A: Verify the rack configuration, external power supply, wiring, polarity, grounding, and power ratings before energizing the system.
