Bently Nevada 3500/92 Communication Gateway

Product Parameters

• Model Number: 3500/92 (Commonly associated with 136188-02 and 190809-02)
• Manufacturer: Bently Nevada (Baker Hughes)
• System Series: 3500 Machinery Protection System
• Communication Protocols: Modbus RTU (via RS485/RS232/RS422) and Modbus TCP/IP (via Ethernet)
• Data Refresh Rate: Up to 1 second (dependent on configuration)
• Configuration: Software-programmable via 3500 Rack Configuration Software
• Backplane Connection: Standard 3500 full-height rack slot
• Operating Voltage: Powered by the 3500 rack backplane
•

Product Description The 3500/92 Communication Gateway is a high-performance module designed to bridge the gap between the Bently Nevada 3500 machinery protection system and external control or monitoring systems. It provides all rack data, including proportional values, statuses, and event logs, to Distributed Control Systems (DCS), Programmable Logic Controllers (PLC), or Plant Historians using the industry-standard Modbus protocol. By facilitating seamless digital integration, this gateway eliminates the need for extensive hard-wiring of individual monitor outputs, providing a centralized and efficient data highway for machinery health information.

Product Applications This gateway is essential for integrated plant operations in power generation, oil and gas, and petrochemical facilities. It is used to export critical vibration and position data from the 3500 monitoring rack into a centralized SCADA or DCS environment for remote operator visualization. It is particularly valuable in large-scale facilities where multiple racks must be monitored from a single control room, enabling automated response strategies based on real-time machinery protection data.

Product Specifications

• Weight: 0.95 kg
• Dimensions: 24.1 cm x 2.4 cm x 10.3 cm
• Country of Origin: United States (USA)
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)

Operational Precautions

• Configuration Integrity: Always backup the Modbus register map after configuration; any changes to the 3500 rack layout may require updates to the register assignments in the gateway.
• Network Isolation: For Ethernet-based Modbus TCP/IP, ensure the module is connected to a secure industrial network to prevent unauthorized access to the machinery protection system data.
• Termination Resistors: When using the RS485 serial interface, ensure proper 120-ohm termination resistors are installed at both ends of the communication bus to prevent signal reflection.
• Firmware Synchronization: Ensure the 3500/92 firmware version is compatible with the other monitor modules in the rack to ensure accurate data polling and status reporting.
