Product Parameters
- Model Number: DS3800HLNE1B1B
- Manufacturer: General Electric (GE)
- Series: Mark IV Speedtronic Control System
- Board Type: LAN Interface / Logic Extension Board
- Microprocessor: On-board processing capabilities
- Communication Interface: Serial and Parallel communication ports
- Voltage Requirement: Standard Mark IV cabinet power distribution
- Input/Output: Digital and Analog signal processing support
Product Description
The DS3800HLNE1B1B is a high-performance circuit board designed for the GE Mark IV Speedtronic turbine control system. It primarily functions as a Local Area Network (LAN) interface or logic extension module, facilitating seamless data exchange between the turbine control processors and external monitoring systems. Built with industrial-grade components, this board ensures high reliability and precise execution of control algorithms in demanding power generation environments.
Product Applications
This board is predominantly utilized in heavy-duty gas and steam turbine control systems. It is essential for industrial power plants, oil and gas refineries, and marine propulsion systems that rely on the Mark IV Speedtronic framework. Its role is critical in maintaining synchronized communication across the control network to ensure operational safety and efficiency.
Product Specifications
- Weight: 0.65 kg (approx. 1.43 lbs)
- Dimensions: 17.8 cm x 12.7 cm x 2.5 cm
- Country of Origin: United States (USA)
- Form Factor: Standard rectangular plug-in PCB
Operational Precautions
- Static Protection: Always wear a grounded ESD (Electrostatic Discharge) wrist strap when handling the board to prevent permanent damage to CMOS components.
- Power Down: Ensure the control cabinet is completely powered off before inserting or removing the circuit board to avoid electrical arcing.
- Configuration: Verify all onboard jumpers and DIP switch settings match your specific system requirements before installation.
- Storage: Store the board in an anti-static bag and a moisture-controlled environment when not in use.
Recommended Similar Product Models
| Model Number | Series | Component Type |
| DS3800HACA1A1A | Mark IV | Analog Input Board |
| DS3800DBRE1A1A | Mark IV | Relay Output Board |
| DS3800HCMC1A1A | Mark IV | Common Memory Board |
| DS3800HCBE1A1A | Mark IV | Communication Board |
| DS3800HPRD1A1A | Mark IV | Power Radio Board |
