- 🌐 Introduction: The AREVA Motor Protection MiCOM P220 (Model: P220C00M11160) numerical relay is engineered for comprehensive protection, control, and monitoring of low and medium-voltage electric motors, delivering reliable thermal overload protection, fault diagnosis, and seamless integration across industrial automation systems.
Product Parameters & Datasheet
- 📐 Dimensions: Compact industrial flush-mounting case measuring approximately 177mm x 159mm x 215mm.
- ⚖️ Weight: Approximately 3.1 kg.
- 🌍 Country of Origin: France / United Kingdom.
- ⚡ Power Supply Rating: Wide-range auxiliary power supply (typically 24 to 250 VDC or 48 to 240 VAC).
- 🔧 Installation Style: Semi-flush panel mounting or 19-inch rack enclosure installation.
- 🌡️ Operating Temperature: −10∘C to +55∘C.
- 湿度 Humidity: Up to 93% non-condensing relative humidity at 40∘C.
- 🛡️ Ingress Protection: IP52 front panel protection against dust and moisture ingress.
- 🔌 Communication Interface: Rear RS485 communication port supporting standard industrial protocols (e.g., Modbus or IEC protocols).
- ⚡ Power Consumption: Maximum 15 W under full operating load.
Application Fields
- Medium-voltage and high-voltage industrial motor protection in power plants.
- Pumping stations, compressor drives, and fan installations in petrochemical facilities.
- Heavy manufacturing conveyor and mill motor management systems.
- Industrial co-generation and auxiliary substation automation schemes.
Product Precautions
- Verify that auxiliary control voltage matches the relay’s rated input specifications prior to energization.
- Ensure all current transformer (CT) secondary circuits are securely short-circuited or isolated before disconnecting the wiring plug terminals.
- Handle the internal electronics and replacement modules using proper electrostatic discharge (ESD) wrist straps and grounding equipment.
- Check that panel cutouts and mounting clips provide a secure mechanical fit to withstand vibration in heavy industrial environments.
Parameter Configuration & Modification Methods
- Configuration and setting adjustments are performed using dedicated MiCOM S1 or compatible support software connected via the front optical communication port or rear serial interface.
- Parameters such as thermal overload curves, start-up current thresholds, and trip time delays can be modified and downloaded directly to the internal non-volatile memory.
Manual/Automatic Mode Switching
- Transitioning between local manual reset commands and automated supervisory control routines is managed through programmable logic inputs, front-panel function keys, or remote SCADA control communication words.
Emergency Trip Operation
- Hardware Trip Execution: High-speed internal output relay contacts immediately trip the motor circuit breaker or contactor upon detecting thermal overload, phase unbalance, or short-circuit fault conditions, operating independently of supervisory software.
Frequently Asked Questions (Q&A)
- Q: How are motor thermal states tracked by the relay?
A: The relay uses a mathematical thermal image algorithm based on measured load currents and motor cooling constants to monitor thermal capacity utilization.
- Q: Can trip history and event logs be retrieved locally?
A: Yes, fault records, event logs, and disturbance recordings are stored in non-volatile memory and can be viewed via the front display panel or downloaded via software.
- Q: What backup power is available for settings during power loss?
A: All configuration settings and recorded logs are stored in non-volatile flash memory, requiring no internal battery backup to retain data.
