๐ง Product Overview
The ABB 3BHE020455R0001 is a PP D103 B01 control system component identified with the additional reference SG2162749032. It is an industrial automation control unit intended for use within compatible ABB control and power-electronics systems.
The available listing identifies the unit as a Control System, with 3BHE020455R0001 as the MPN and PP D103 B01 / SG2162749032 as additional part references. The same part number is also associated in market listings with ABB excitation and AC 800PEC-related control applications, but the exact system function should be confirmed from the equipment nameplate and project documentation before replacement.
The referenced unit is listed as used. For legacy ABB equipment, matching the complete part number is especially important because similar-looking control assemblies can have different hardware revisions or application configurations.
โ๏ธ Key Features
- ABB PP D103 B01 control system
- Main part number: 3BHE020455R0001
- Additional reference: SG2162749032
- Industrial control-system application
- Suitable for maintenance and replacement of compatible ABB equipment
- Compact electronic control assembly
- Designed for integration with associated ABB control hardware
- Used industrial equipment
- Listed weight: approximately 880 g
- Country of origin: not specified
The exact product listing identifies the part as an ABB Control System and confirms the PP D103 B01 and SG2162749032 references.
๐ Product Datasheet
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | PP D103 B01 |
| Main Part Number | 3BHE020455R0001 |
| Additional Part Number | SG2162749032 |
| Product Type | Control System |
| Application | Industrial Automation / Control |
| Series | PP D-Series |
| Control Architecture | Configuration dependent |
| Input Specification | Verify from nameplate |
| Output Specification | Verify from nameplate |
| Communication | System dependent |
| Mounting | Cabinet/system dependent |
| Revision | Verify from unit label |
| Country of Origin | Unknown / not specified |
| Weight | Approx. 880 g |
| Condition | Used |
The 880 g weight and unknown country of origin are consistent with current matching listings for this exact part number.
โก Operating Function
The PP D103 B01 functions as a control-system component rather than a general-purpose PLC I/O module. Its job is dependent on the larger ABB system in which it is installed.
Market references associate 3BHE020455R0001 / PP D103 B01 with ABB AC 800PEC and excitation-control applications. In these installations, the control electronics form part of the regulation and monitoring architecture used to manage power-electronic equipment.
Because the exact cabinet and firmware configuration are not specified by the part number alone, the unit should be treated as a system-specific control component. Confirm the original application, firmware, hardware revision, and mating assemblies before commissioning.
๐ ๏ธ Installation & Configuration
Before replacing an existing PP D103 B01 unit:
- Confirm the complete part number 3BHE020455R0001.
- Check the PP D103 B01 marking.
- Verify the SG2162749032 reference where applicable.
- Compare the hardware revision with the existing unit.
- Photograph and record all cable and connector positions before removal.
- Inspect connectors for oxidation, contamination, or bent contacts.
- Confirm the compatible rack, controller, or power-electronics assembly.
- Verify firmware and configuration requirements.
- Perform a controlled power-up after installation.
- Check system diagnostics and communication status before returning the equipment to service.
Do not assume that another ABB PP D-series board is a direct replacement simply because the physical appearance is similar.
๐ Maintenance Tips
Store the module in an ESD-safe environment when it is outside the control cabinet.
During inspection, check the PCB for corrosion, damaged components, loose connectors, contamination, and signs of overheating. Particular attention should be paid to connector contacts and any board-to-board interfaces.
For a used replacement unit, functional testing should ideally include power-up verification, communication checks, system diagnostics, and comparison against the original controller’s operating parameters.
Keep a record of the installed part number and hardware revision. This information can save considerable time when sourcing a future spare.
โ Frequently Asked Questions
Q1: What is ABB 3BHE020455R0001?
It is an ABB PP D103 B01 control-system component.
Q2: What is the additional part number?
SG2162749032 is listed as an additional part reference for this unit.
Q3: Is this a PLC I/O module?
It should not automatically be classified as a conventional PLC I/O card. The available identification describes it as a Control System component.
Q4: What systems may use this component?
Available market references associate this part with ABB AC 800PEC and excitation-control applications, but exact compatibility should be confirmed against the original system documentation.
Q5: What is the weight?
The current matching listings specify approximately 880 g.
Q6: Is the unit new?
No. The referenced listing identifies the unit as used.
Q7: Can PP D103 B01 be replaced by another ABB PP D-series model?
Not without verification. The complete part number, hardware revision, firmware, connectors, and system application should match.
Q8: What should be checked before installation?
Check the nameplate, hardware revision, connectors, original system configuration, firmware requirements, and associated control hardware.
Q9: Does the part number alone define all electrical specifications?
No. The available listing does not provide a complete electrical datasheet, so voltage, current, communication, and I/O details should be verified from the original equipment documentation.
Q10: Is this suitable as a maintenance spare?
Yes, provided the complete part number and system compatibility are confirmed. A tested spare can be useful for reducing downtime on legacy ABB control equipment.
๐ Recommended ABB Models
For customers maintaining ABB industrial control and power-electronics systems, the following related models may also be relevant:
- ABB 3BHE023784R2630 PPD113
- ABB PPD103 B01 Control System
- ABB AC 800PEC Control System
- ABB PPD113A
- ABB PPD115
- ABB UNITROL 5000 Excitation System
- ABB UNITROL 6000 Excitation System
- ABB PM866AK01 Controller
- ABB PM891K01 Controller
- ABB CI854A PROFIBUS-DP Interface
Exact interchangeability should always be checked by complete ABB part number rather than product family name alone.
๐ญ Application Summary
The ABB 3BHE020455R0001 PP D103 B01 is a compact industrial control-system component used in specialized ABB automation and power-control environments. Its additional SG2162749032 reference provides another useful identification point when matching an existing spare.
For replacement work, the safest approach is to match 3BHE020455R0001, PP D103 B01, SG2162749032, hardware revision, connectors, and the original system configuration. Since the available listing does not provide a complete electrical specification, the original cabinet documentation or nameplate should be used to confirm final compatibility before installation.
