🔹 Product Overview
The ABB 3HNE04687-1/03 is an AMA module designed for use in ABB IRB 5400 industrial robotics systems. It is associated with the electrical and control architecture of the IRB 5400 robot family, which is widely used in automated painting and coating applications.
The module is identified by ABB part number 3HNE04687-1/03 and may be found together with related components and assemblies carrying part numbers such as 3HNE06911-1 and 3HNE04508-1. Before replacement, the complete hardware configuration and all connected assemblies should be checked carefully.
The ABB IRB 5400 family includes several robot versions for industrial paint automation. Depending on the robot configuration, the system can include slim-arm and process-arm designs for floor-mounted or rail-mounted applications.
⚙️ Key Product Features
• Designed for ABB IRB 5400 robotics applications
• AMA electronic module assembly
• ABB part number 3HNE04687-1/03
• Used in industrial robotic automation systems
• Suitable for replacement and maintenance applications
• Designed for integration with related robot electrical assemblies
• Compact electronic module construction
• Important to verify matching hardware and revision information before installation
• Intended for professional industrial robotics maintenance
• Suitable for spare-parts inventory and system restoration projects
📊 Product Datasheet
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | 3HNE04687-1/03 |
| Series | IRB 5400 Robotics |
| Product Name | AMA Module |
| Product Type | Robotics Electronic Module |
| Application | ABB IRB 5400 Robot System |
| Related Part Number | 3HNE06911-1 |
| Related Assembly Reference | 3HNE04508-1 |
| Module Identification | AMA |
| Manufacturer | ABB Robotics |
| Weight | Approx. 1.52–1.63 kg |
| Installation | IRB 5400 Robotics System |
| Robot Application | Industrial Automation |
| Typical Industry | Automotive Paint Automation |
| Controller Compatibility | Must Be Verified by System Configuration |
| Electrical Rating | Refer to Module Nameplate and System Documentation |
| Input Voltage | Configuration Dependent |
| Output Specification | Configuration Dependent |
| Dimensions | Refer to Actual Physical Unit |
| Origin | Verify from Product Nameplate |
| Condition | New Surplus / Subject to Actual Stock Condition |
🛠️ Product Function
The ABB 3HNE04687-1/03 AMA Module is used as part of the electrical architecture supporting ABB IRB 5400 robotic equipment. Modules of this type are normally installed as part of a larger robot assembly and work together with other dedicated boards, cables, and electronic components.
Because the IRB 5400 is a specialized robotics platform, component replacement should not be based only on the model number. The complete part number, hardware revision, connector arrangement, related assemblies, and robot configuration should be checked before installation.
The IRB 5400 product family includes several robot configurations developed for paint and coating operations, including Slim Arm and Process Arm versions. ABB documentation lists multiple IRB 5400 variants with applications in automated paint systems.
🔧 Installation and Maintenance Notes
Before replacing the AMA module, completely disconnect the robot system according to the applicable ABB safety and maintenance procedures.
Check the existing module label carefully and confirm that the installed part number matches 3HNE04687-1/03.
Inspect all connectors and associated cables for bent pins, oxidation, mechanical damage, or signs of overheating.
Do not force the module into position if the connector alignment does not match the original assembly.
After installation, inspect the complete robot electrical system and perform the required controller diagnostics before returning the robot to production.
For spare or surplus inventory, verify the actual module condition, nameplate information, connector condition, and compatibility with the installed robot before use.
❓ FAQ
Q1: What is the main application of ABB 3HNE04687-1/03?
A: It is an AMA module associated with ABB IRB 5400 industrial robotics systems.
Q2: Which robot family uses this module?
A: The module is associated with the ABB IRB 5400 robotics platform.
Q3: Is this module used as a standalone device?
A: No. It is normally used as part of a larger robot electrical and electronic system.
Q4: What should be checked before replacing the module?
A: Confirm the complete ABB part number, hardware configuration, related assemblies, connector layout, and robot version.
Q5: What is the approximate weight of the module?
A: Available product information indicates an approximate weight in the range of 1.52 to 1.63 kg.
Q6: Can this module be used in every ABB robot?
A: No. Compatibility must be confirmed specifically for the IRB 5400 configuration and the associated electrical system.
Q7: Why are related part numbers important?
A: Related boards, cables, and assemblies may have different revisions or connection arrangements. Checking these numbers helps reduce compatibility risks during maintenance.
Q8: Is professional installation recommended?
A: Yes. Installation should be carried out by qualified personnel familiar with ABB industrial robot maintenance and electrical safety procedures.
🤖 Recommended ABB Robotics Models
- ABB 3HNE06911-1 | Robotics Electronic Assembly
- ABB 3HNE04508-1 | Robotics Cable Assembly
- ABB 3HNE05890-1/01 | Robotics Electronic Module
- ABB 3HNE01885/03 | Robot Electrical Component
- ABB 3HNE08415-1/00 | Robotics Control Component
- ABB 3HNE00010-1/09 | Robot System Module
- ABB IRB 5400-12 | Slim Arm Paint Robot
- ABB IRB 5400-22 | Process Arm Paint Robot
- ABB IRB 5500-22 | Process Arm Paint Robot
- ABB IRC5P | Paint Robot Controller
📦 The ABB 3HNE04687-1/03 AMA Module is a specialized spare component for ABB IRB 5400 robotic systems. For replacement projects, matching the complete ABB part number and checking the existing hardware configuration are recommended before installation.
