BEIJER X2 MARINE 15-B2 | Remote Control Panel

🔧 Product Overview

The BEIJER X2 MARINE 15-B2 is a 15-inch-class marine HMI operator panel designed for monitoring, control, and visualization in demanding marine and industrial environments.

The panel uses a 15.4-inch TFT-LCD display with 1280 × 800 resolution and a resistive touchscreen. Its marine-oriented design combines a powder-coated aluminum housing with a sealed front panel and multiple communication interfaces for connection to PLCs, controllers, drives, and other automation equipment.

The X2 marine 15-B2 is designed for panel mounting or VESA 75 × 75 installation. The official technical data specifies a 394 × 270 mm panel cutout and a 410 × 286 mm front-panel size.

⚙️ Key Features

• BEIJER X2 marine 15-B2 operator panel
• 15.4-inch TFT-LCD display
• 1280 × 800 pixel resolution
• Resistive touchscreen
• iX runtime platform
• 24 VDC power input
• Dual 10/100 Mbit Ethernet ports
• RS-232 and RS-422/RS-485 communication
• CAN interface
• Panel mount and VESA 75 × 75 mounting
• Powder-coated aluminum housing
• IP65 front-panel sealing
• Marine-oriented construction
• Suitable for shipboard and industrial control applications
• Designed for integration with PLC and automation systems

Beijer Electronics lists marine approvals including KR, LR, ABS, CCS, NK, DNV GL, and BV for the X2 marine 15 family.



📋 Product Datasheet

Parameter	Specification
Brand	BEIJER Electronics
Model	X2 MARINE 15-B2
Product Type	Remote Control Panel / HMI Operator Panel
Series	X2 marine
Display Size	15.4 inch
Display Type	TFT-LCD with LED backlight
Resolution	1280 × 800 pixels
Touchscreen	Resistive
Input Voltage	24 VDC
Permitted Voltage Range	18–32 VDC
Maximum Power Consumption	31.2 W
Ethernet	2 × 10/100 Mbit Base-T
Serial Communication	RS-232 / RS-422 / RS-485
CAN	1 × CAN, 0.5 Mbit
Front Panel Size	410 × 286 × 8 mm
Cutout Size	394 × 270 mm
Mounting Depth	53 mm
Mounting	Panel / VESA 75 × 75
Front Protection	IP65
Weight	Approx. 3.85 kg
Housing	Powder-coated aluminum
Application Memory	2 GB SSD/eMMC, 1.5 GB available for application
RAM	1 GB
Condition	Verify against the supplied unit

The electrical and mechanical values above are based primarily on Beijer Electronics’ official X2 marine 15-B2 documentation.



🖥️ Operating Function

The X2 MARINE 15-B2 functions as an HMI/operator interface between the machine or vessel automation system and the operator. The display can be used for process values, status information, alarms, control commands, trends, and other configured HMI functions.

Configuration is performed using Beijer Electronics’ iX Developer environment. The panel can communicate with external controllers through its available serial, Ethernet, and CAN interfaces, depending on the selected driver and system architecture.

The dual Ethernet interfaces are useful for integrating the panel into industrial networks, while the serial ports provide options for legacy PLCs and other control equipment.



🔩 Installation & Configuration

1. Verify the complete model designation before installation.
2. Prepare a clean panel cutout measuring approximately 394 × 270 mm.
3. Confirm that the mounting surface is smooth and free from burrs or debris.
4. Install the HMI into the panel and secure it according to the manufacturer’s installation procedure.
5. Maintain sufficient clearance behind the panel for cables and connectors.
6. Connect a suitable 24 VDC power supply within the specified 18–32 VDC range.
7. Connect Ethernet, serial, or CAN communication according to the control-system design.
8. Load or configure the required HMI application using the appropriate Beijer software.
9. Verify communication with the PLC or controller before putting the machine into normal operation.
10. Test touchscreen operation, alarms, communication, display performance, and power-loss recovery during commissioning.

Beijer specifically recommends using the official cutout dimensions and installing the panel on a stable surface.



🛠️ Maintenance Tips

Keep the touchscreen and front-panel sealing surface clean. Dirt or mechanical damage around the mounting seal can affect the environmental protection of the installed panel.

Inspect Ethernet, serial, CAN, and power connectors periodically, especially in marine environments where vibration, humidity, salt exposure, and temperature changes can accelerate connector degradation.

Do not use excessive force on the resistive touchscreen. The manufacturer specifies approximately one million finger-touch operations for the panel.

For a replacement unit, compare the hardware version, display condition, touchscreen response, communication ports, and installed application before returning the panel to service.



❓ Common Questions

Q: What is the X2 MARINE 15-B2?
It is a 15-inch-class marine HMI/operator panel from BEIJER Electronics designed for industrial and marine control applications.

Q: What is the display resolution?
The panel uses a 1280 × 800 pixel TFT-LCD display.

Q: What power supply does it require?
The official specification is 24 VDC, with an operating range of 18–32 VDC.

Q: Does it have Ethernet?
Yes. The X2 marine 15-B2 provides two 10/100 Mbit Ethernet ports.

Q: What serial interfaces are available?
The panel supports RS-232 and RS-422/RS-485 communication through its serial interface configuration.

Q: Does it support CAN?
Yes. The official specification lists one CAN interface rated at 0.5 Mbit.

Q: What is the panel cutout size?
The required cutout is approximately 394 × 270 mm.

Q: What is the front-panel protection rating?
The front panel is specified as IP65. The rear panel is specified as IP20.

Q: Can this panel replace another X2 marine model directly?
Not automatically. Models such as the HB, SC, and HB SC versions have different hardware configurations. The complete model should be matched before replacement. Beijer lists these as separate X2 marine variants.

Q: Is the X2 MARINE 15-B2 suitable for shipboard applications?
Yes. The X2 marine 15 family is designed for marine applications and carries multiple marine approvals, including DNV GL, KR, LR, ABS, CCS, BV, and NK.



🔄 10 Related BEIJER Models

1. BEIJER X2 marine 7
2. BEIJER X2 marine 7 HB
3. BEIJER X2 marine 7 SC
4. BEIJER X2 marine 7 HB SC
5. BEIJER X2 marine 7 CAN
6. BEIJER X2 marine 15 HB
7. BEIJER X2 marine 15 SC
8. BEIJER X2 marine 15 HB SC
9. BEIJER X2 pro 15
10. BEIJER X2 control 15

The X2 marine 15, X2 marine 15 HB, X2 marine 15 SC, and X2 marine 15 HB SC are separate configurations. They share the same general 15-inch platform but should not be assumed to have identical hardware.



🏭 Application Summary

The BEIJER X2 MARINE 15-B2 is a practical operator-interface solution for marine automation, vessel monitoring, machinery control, and industrial process visualization.

Its 15.4-inch display, resistive touchscreen, dual Ethernet ports, serial communications, CAN interface, 24 VDC supply, and marine-oriented construction make it suitable for integration into control cabinets and operator stations where reliable HMI access is required.

For replacement applications, the most important checks are the exact model suffix, panel cutout, communication configuration, power requirements, installed HMI application, and marine certification requirements. Matching the complete model number is recommended rather than selecting a replacement solely by screen size.
