HONEYWELL UDA2182-CC1-NN2-NN-N-P0C0-EE | Universal Dual Analyzer

🔧 Product Overview

The HONEYWELL UDA2182-CC1-NN2-NN-N-P0C0-EE is a Universal Dual Analyzer designed for industrial process measurement and analytical applications.

The UDA2182 platform supports flexible measurement configurations for pH, ORP, contacting conductivity, and dissolved oxygen. The specific model code identifies the selected channel and output configuration, allowing the analyzer to be matched to different process measurement requirements.

This version is specified for 240 VAC, 50/60 Hz operation. It is suitable for applications where continuous analytical measurements, alarm handling, and analog signal transmission are required.

⚙️ Key Features

• Honeywell UDA2182 Universal Dual Analyzer
• Full model: UDA2182-CC1-NN2-NN-N-P0C0-EE
• Dual-channel analytical measurement platform
• Channel 1 configured for contacting conductivity
• Channel 2 configured as no input
• Standard 4–20 mA analog outputs
• Two standard alarm relays
• Infrared communications interface
• 240 VAC power configuration
• 50/60 Hz operating frequency
• Suitable for industrial process monitoring
• Supports Honeywell analytical sensors and compatible measurement equipment



📋 Product Datasheet

Parameter	Specification
Brand	HONEYWELL
Model	UDA2182-CC1-NN2-NN-N-P0C0-EE
Base Model	UDA2182
Product Type	Universal Dual Analyzer
Measurement Type	Dual Input Analytical Analyzer
Channel 1	Contacting Conductivity
Channel 2	No Input
Standard Analog Outputs	2 × 4–20 mA
Alarm Relays	2
Power Supply	240 VAC
Frequency	50/60 Hz
Communication	Infrared Communication Port
Operating Temperature	0 to 60 °C
Country of Origin	Mexico*
Condition	New / Surplus condition according to referenced listing
Application	Industrial Process Measurement

*Country of origin is based on available listing information for this exact model family; verify the nameplate for the individual unit. The referenced listing specifies 120/240 VAC, 50/60 Hz, 0–60 °C and Mexico as country of origin.



🏭 Operating Function

The UDA2182 is designed to receive analytical measurement signals from process sensors and convert them into useful process information for operators and control systems.

For this configuration, the first channel is selected for contacting conductivity measurement, while the second channel is not populated with an analytical input. The analyzer can provide analog outputs for integration with a PLC, DCS, recorder, or other process-control equipment.

The standard UDA2182 configuration includes two 4–20 mA outputs and two alarm relays. This makes the instrument suitable for both continuous measurement and process alarm functions.

Typical applications include:

• Water and wastewater treatment
• Boiler and feedwater monitoring
• Industrial water-quality control
• Chemical process monitoring
• Process conductivity measurement
• General industrial analytical systems



🔌 Power & Wiring Notes

For 230/240 VAC installations, the UDA2182 manual specifies a 0.15 A time-delay or slow-blow fuse. Power is connected through terminals L1 and L2/N, with protective grounding connected to the grounding stud on the case.

Before applying power:

• Confirm that the supply voltage matches the analyzer rating.
• Verify L1 and L2/N wiring.
• Connect the protective earth correctly.
• Check the sensor and signal wiring.
• Confirm the output and relay wiring.
• Make sure the enclosure/bezel is properly closed before energizing the unit.

Incorrect supply voltage can damage the analyzer, so the nameplate should always be checked before commissioning.



🛠️ Installation & Maintenance

Before installation

• Verify the complete model number.
• Check the power-supply configuration.
• Confirm the conductivity sensor type.
• Inspect terminals and connectors for corrosion or damage.
• Compare the existing wiring with the analyzer terminal assignment.

During installation

• Disconnect power before opening the enclosure.
• Use appropriate electrical safety procedures.
• Maintain proper protective grounding.
• Route sensor and power wiring separately where practical.
• Verify analog output and relay wiring before startup.

Maintenance

Keep the analyzer enclosure clean and dry. Periodically inspect sensor connections, terminal blocks, wiring glands, and the display/interface for signs of moisture, corrosion, or physical damage.

For troubleshooting, compare the actual process measurement with the displayed value and the corresponding analog output. This can help isolate problems between the sensor, wiring, analyzer input, and control-system interface.



❓ Common Questions

Q: What is the complete model number?
A: UDA2182-CC1-NN2-NN-N-P0C0-EE.

Q: What is the base product?
A: It is a Honeywell UDA2182 Universal Dual Analyzer.

Q: What is Channel 1 configured for?
A: The CC1 selection identifies contacting conductivity as the Channel 1 input.

Q: What is Channel 2 configured for?
A: NN2 indicates that Channel 2 has no analytical input selected.

Q: What outputs are available?
A: The standard UDA2182 includes two 4–20 mA outputs and two alarm relays.

Q: What power supply does this version use?
A: The referenced item is specified for 240 VAC, 50/60 Hz.

Q: What temperature range does the analyzer support?
A: Available listing information specifies an operating temperature range of 0 to 60 °C.

Q: Can this unit measure pH or dissolved oxygen?
A: The UDA2182 family supports pH, ORP, conductivity, and dissolved oxygen configurations, but the exact model code determines the installed input configuration. This particular model is configured with Channel 1 for contacting conductivity.

Q: What should be checked before replacement?
A: Match the complete model code, power rating, input configuration, outputs, terminal arrangement, and sensor type with the existing installation.



🔄 Recommended HONEYWELL Models

1. HONEYWELL UDA2182-CC1-CC2 — Universal Dual Analyzer
2. HONEYWELL UDA2182-PH1-PH2 — Dual pH Analyzer
3. HONEYWELL UDA2182-PA1-PA2 — Dual pH Preamp Analyzer
4. HONEYWELL UDA2182-DM1-DM2 — Dual Dissolved Oxygen Analyzer
5. HONEYWELL UDA2182-DB1-DB2 — Dual Dissolved Oxygen Analyzer
6. HONEYWELL UDA2182-CC1-NN2 — Conductivity Analyzer
7. HONEYWELL UDA2182-PH1-NN2 — Single pH Input Analyzer
8. HONEYWELL UDA2182-PA1-NN2 — pH Preamp Analyzer
9. HONEYWELL UDA2182-DM1-NN2 — Dissolved Oxygen Analyzer
10. HONEYWELL UDA2182-DB1-NN2 — Dissolved Oxygen Analyzer

These are configuration examples within the UDA2182 family. The actual replacement must be selected according to the required sensor input, analog outputs, relay configuration, power supply, and communication requirements.



📦 Application Summary

The HONEYWELL UDA2182-CC1-NN2-NN-N-P0C0-EE is a practical analytical instrument for industrial process monitoring, particularly where conductivity measurement and analog process integration are required.

Its combination of analytical input capability, 4–20 mA outputs, alarm relays, and flexible UDA2182 configuration makes it suitable for integration into existing industrial measurement and control systems.

For replacement purchasing, always match the complete UDA2182 model code, not just the UDA2182 base number. This is especially important because different suffix combinations represent different sensor inputs and output configurations.
